- Page 1 Rio 6.0 ADJUSTABLE BASE | OWNER’S MANUAL Customer Service : 1-888-550-3746...
-
Page 2: Table Of Contents
Table of contents Safety Precautions and Usage Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 Parts List . -
Page 3: Safety Precautions And Usage Statements
Safety precautions and usage statements Attention: Important Safety Disclaimers Read the following information before using this product. Failure to use a surge protection device could compromise safety or cause product malfunction and could void the electrical portion of your warranty. TO REDUCE THE RISK OF SHOCK, BURNS, FIRE OR INJURY: Emergency stop –... - Page 4 All Ergomotion adjustable foundations, depending on make and model, are designed and manufactured to perform and function within designated quality control parameters. Bases are subject to meticulous and rigorous inspections during MATERIALS be ±...
- Page 5 Safety precautions and usage statements with the kids or grandkids. The extra movement will help the adjustable base WEIGHT LIMITS: respond to weight and temperature changes. Some of the materials in our This product is not rated to support weights in excess of 750 pounds (340 kg). adjustable bases such as the woods, metals and plastics used in the platform, The base will structurally support this weight, provided it is evenly distributed frame and components are sensitive to moisture content and temperature...
-
Page 6: Parts List
Parts list Before discarding the packing materials - ensure all the parts are accounted for. All electronics and components that need to be installed are located in boxes under the base or attached to the frame. Wireless Remote Control (1) Mattress Retainer Bar (1)* Legs (6) Power Cord (1) -
Page 7: Base And Remote Overview
Base and remote overview Head Massage Motors Massage Timer & Indication Lights Head Tilt Motor Increase the head Increase the foot massage intensity massage intensity Head Tilt Adjustment Lumbar Adjustment Lumbar Motor Underbed Lighting On/Off Head Motor Underbed Underbed Lifts & lowers the Lifts &... -
Page 8: Quick Reference Guide
Quick reference guide Not to scale. For illustration purposes only. Read all instructions before beginning installation. ELECTRONICS OVERVIEW Sync Cord Massage Motors USB Ports Remote Control Underbed Lighting Control Box Power Cord Input Cable Power Supply Battery Backup Strap Head Tilt Motor Head Motor Lumbar Motor Foot Motor... -
Page 9: Installation Guide
Uncoil the power cord and connect to the power supply. Place power supply on the ground and extend from the base. Ensure that the power supply and all attached cords are directed toward the desired surge protector. For customer support, visit www.ergomotion.com or call: 1-888-550-3746... - Page 10 Ensure batteries are correctly installed in the back of the remote. Quickly test functions to verify proper setup before placing mattress on base. Return the base to a flat position before placing the mattress on top. For customer support, visit www.ergomotion.com or call: 1-888-550-3746...
-
Page 11: Bluetooth Setup
Bluetooth Setup To operate the base from a smart device, the “Ergomotion Sync” application must be downloaded to the desired smart device from the App Store (Apple) or Google Play Store (Android). STEP 1 STEP 3 Click OK when prompted to allow... -
Page 12: Remote Control
Remote control The remote control arrives paired to the adjustable base. Three (3) AAA batteries are required to operate the remote. REMOTE FUNCTIONS A. Head Massage: Cycle through 3 head massage intensities (Low > Medium > High > Off) After 10 minutes, massage timer will automatically turn off. - Page 13 Remote control REMOTE FUNCTIONS Lights: Turn the underbed lights On/Off. K. Zero-G®: Preset position that adjusts your legs to a higher level than your heart helping to relieve pressure off the lower back and promote circulation. L. Programmable Presets*: Save a customizable position. Flat: Return the adjustable base to a flat position.
-
Page 14: Pairing Remote Control
LED light on the control box will stop illuminating. Release the PAIR button on the remote. STEP 3 Test all remote functions. If the remote buttons do not impact the adjustable base movements, please repeat the process again or call Ergomotion customer service: 1-888-550-3746... -
Page 15: Connecting Strap
Connecting strap (optional) If a split setup is being installed, optional plastic connecting straps can be used to help secure the bases together. To purchase optional accessories, please call 1-888-550-3746. STEP 1 STEP 3 With the bases in their desired location, Re-tighten legs. -
Page 16: Syncing Two Bases
Syncing two bases (optional) A Sync Cord is included with the base. Not available on Queen, Full or Full-Long size bases. The Sync Cord connects the two control boxes to a single remote for the synchronization of two bases. This process is most commonly used for syncing two connected TXL bases. STEP 1 Unplug the base(s) from power source. -
Page 17: Headboard Brackets
Headboard bracket installation guide (optional) Headboard Brackets are an optional accessory and are not included. A 9/16" abd 1/2" socket and crescent wrench are needed to complete installation. STEP 1 STEP 2 a. Measure the distance between the mounting holes on the headboard a. -
Page 18: Emergency Battery Backup Strap
Battery backup strap (optional) For emergency use only, in case of a power outage. Batteries are not to be used for normal operation of the bed. STEP 1 STEP 3 Disconnect the Power Supply from the input power cord. Connect the Battery Backup Strap to the (2) Alkaline 9 Volt batteries. Do not mix brand name Batteries. -
Page 19: Troubleshooting
Ensure that the remote control is paired to the bed base. See page 12 for more information. If issue is not resolved by following the instructions above, locate serial number on warranty card or back of remote and call Ergomotion Customer Service: US 1-888-550-3746... - Page 20 Nationwide Customer Service ©2023 Ergomotion Inc V002_04/2023 Phone 1 .888 .550 .3746 Email info@ergomotion.com www.ergomotion.com Serial Number:...
Need help?
Do you have a question about the Rio 6.0 and is the answer not in the manual?
Questions and answers
can i add a biug fig mattress to the rio 6 can it handle it
The Big Fig mattress weighs about 120 pounds, and it is designed to support heavier individuals. The Ergomotion Rio 6.0 adjustable base has a weight limit of 750 pounds, including the mattress and bedding, as long as the weight is evenly distributed. Based on this, the Rio 6.0 can handle a Big Fig mattress.
