- Page 1 HVLP SPRAY GUNS ECO series Instruction manual mod. ECO aircom.it...
-
Page 2: Available Models
AVAILABLE MODELS mod. ECO Maximum efficiency with extremely low atomization pressures AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®... - Page 3 ECO series ECO series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Health Hazard
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... -
Page 5: Installation
ECO series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,95 kg Gun size: see dimensioned views VIDEO TUTORIALS ►... -
Page 6: Installation And Start-Up
ECO series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø 6 ÷ 8 Plunger opening ≥... -
Page 7: Adjustment Sequence
ECO series ADJUSTMENT SEQUENCE Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. Connect the atomization air, control air and product piping to the junctions shown on the previous page. -
Page 8: Technical Data
ECO series TECHNICAL DATA HEAD L-A HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) ø 0,45 0,55 ø ø ø NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. - Page 9 ECO series TECHNICAL DATA HEAD N-A HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 0,35 ø 0,45 ø 0,65 ø ø NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec.
-
Page 10: Troubleshooting
ECO series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gaskets part. [O4] worn out Replace gaskets part. [O4] worn out The head part. [C5], the nozzle part. [C4] eand the rod part. [C12] are worn out. - Page 11 HVLP SPRAY GUNS ECO series mod. ECO Spare parts and components aircom.it...
-
Page 12: Spare Parts
ECO series SPARE PARTS mod. ECO DETAILS LIST [x1] Spring [x1] Spring [x1] Gasket [x1] Gasket [x1] Secondary body [x1] Threaded insert [x1] Nozzle [x1] Head [x1] Ferrule [x1] Plunger [x1] Stopper + positioner [x1] Hand wheel [x1] Rod [x1] Gasket... - Page 13 ECO series CNN COMPATIBILI Cap-Nozzle-Needle mod. ECO NOZZLE NEEDLE NOZZLE NEEDLE aircom.it Spare parts and components - 13...
-
Page 14: Certified Quality
ECO series CERTIFIED QUALITY CERTIFICATIONS THREE-COLOR INSERT AIRCOM products certified Each gun is marked with a three-color ® according to norm EN 13 966 - 1 (VDMA- three-dimensional seal. It represents an Einheisblatt 366) therefore additional guarantee of authenticity and... - Page 15 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 16 DISCOVER ALL PRODUCTS Follow us aircom.it...
