Evaluation Board User Guide
EV Kit Photo
Table 1. Jumper Connection Guide
JUMPER
J1
J2
J3
J4
J5
J6
Default options are in bold.
analog.com
DEFAULT CONNECTION
Not Installed
Not Installed
2-3
1-2
1-2
2-3
2-3
1-2
Not Installed
MAX49918 Evaluation Kit
FEATURE
Set the least bit of I2C device address to 0
Set the least bit of I2C device address to 1
Connect REF1 to VDD
Connect REF1 to GND
Connect REF2 to GND
Connect REF2 to VDD
