LED Information
The following table summarizes the information carried by the drive's LEDs:
Type of Blink
a
Off
b
On
c
Slow Flash
d
Fast Flash
e
All Flash
a. Off: no color in the LED
b. On: Blue and not blinking
c. Slow flash: flashes blue for 3-1/2 seconds and off for 1/2 second
d. Fast flash: flashes blue for 1/4 second and off for 1/4 second
e. All LEDs flashing: all flash blue for 1/4 second and off for 1 second
Spectra 2K Library AIT-5 Drive Upgrade
LED Type
Tape Motion
No Tape
Tape Loaded
Tape access in progress (read/
write)
Tape access in progress (other)
Hardware error occurred
Cleaning Request
Cleaning is not necessary
Cleaning request
Cleaning is not completed
N/A
12
Replace Tape
No media error occurred
Media error occurred
N/A
N/A
