Speco CVC-927PTZ Specification Sheet

Indoor/outdoor high performance ptz dome camera specodome accessories: corner mount, parapet mount, pole mount, flush mount hardware, t-bar mounting adapter
Hide thumbs Also See for CVC-927PTZ:

Advertisement

Corner Mount

CM-927
Features:
3.35"
• Low cost
• Die cast and aluminum
• Easy to install
Specifications:
Enclosure mounting . . . . .Ten (10) M6 x 15mm hex head
Machine screw (supplied)
Construction Finish . . . . .Die cast and aluminum
Finish . . . . . . . . . . . . . . . . . .Light-gray polyester powder coat
Maximum load . . . . . . . . .63.5 lb.
Dimension . . . . . . . . . . . . .See diagram above
Weight . . . . . . . . . . . . . . . .1.31 lb.

Pole Mount

PM-927
2.8"
Features:
• Low cost
• Die cast and aluminum
• Easy to install
Specifications:
Enclosure mounting . . . . .Ten (10) M6 x 15mm hex head
Machine screws (supplied)
Two (2) M10 x 90mm hex head
Machine screws (supplied)
Two (2) M10 hex nuts (supplied)
Construction Finish . . . . .Die cast and aluminum
Finish . . . . . . . . . . . . . . . . . .Light-gray polyester powder coat
Maximum load . . . . . . . . .63.5 lb.
Dimension . . . . . . . . . . . . .See diagram above
Weight . . . . . . . . . . . . . . . . .2.12 lb.
Parapet Mount
PMT-927
Specifications:
Construction Finish . . . . .Aluminum, steel & stainless hrdw
Finish . . . . . . . . . . . . . . . . . .Light-gray polyester powder coat
Maximum load . . . . . . . . .20 lb.
Dimension . . . . . . . . . . . . .See diagram above
Weight . . . . . . . . . . . . . . . .23 lbs.
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
specodome accessories
1.6"
3.2"
4.2"
1.97"
4.7"
M6 TAP"
1.6"
4.7"
7"
17.7"
12.2"
35.85"
5.9"
For more information contact us at:
Flush Mount Hardware
FLM-927
This mounting device enables the dome camera to be
mounted to the suspended ceiling. The mounting clamps
which are affixed to the ceiling tile, attach directly to the
dome's mounting base for a quick and easy installation.
Specifications:
Construction . . . . . . . . . . .Steel and injection molded plastic
Maximum Load . . . . . . . . .Approx. 4.4 lb.
Dimensions . . . . . . . . . . . .See diagram below
4.9"
3.5"
T-Bar Mounting Adapter
TBM-927
4.7"
The mount enables the dome to be mounted to the T-bar of
a suspended ceiling. The mounting clamps, which are affixed
to the T-bar, attach directly to the dome's mounting base for
a quick and easy installation.
Features:
• Easy to install
• Indoor applications
• Steel construction
Specifications:
Construction . . . . . . . . . . .Steel 1.6t
Maximum Load . . . . . . . . .Approx. 4.4 lb.
Finish . . . . . . . . . . . . . . . . . .Light-gray polyester powder coat
4.6"
8.7"
• Cable feed through hole
conceals wiring
• Light duty ceiling mount
Specifications subject to change
