- Page 1 SPECO TECHNOLOGIES KEYBOARD CONTROLLER KBD-927 Instruction Manual Please read this manual thoroughly before use and keep it handy for future reference. Rev.040130...
-
Page 2: Warning And Caution
WARNING AND CAUTION WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Ce Compliance Statement
FCC COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS READ INSTRUCTIONS -- All the safety and operating instructions should be read before the appliance is operated. RETAIN INSTRUCTIONS -- The safety and operating instructions should be retained for future reference. CLEANING -- Unplug video monitor or equipment from the wall outlet before cleaning. -
Page 5: Table Of Contents
Contents Table of Chapter 1.0 INTRODUCTION 1.1 Features 1.2 Unpacking Chapter 2.0 INSTALLATION 2.1 Connection Diagram 2.2 Dip Switch Setting 2.3 Keyboard Setup 2.4 Install with ADR series 2.5 Install with SDR series 2.6 Install with IDR series Chapter 3.0 OPERATION 3.1 Multiplexer Control 3.2 Keyboard Lock/Unlock 3.2 Summary of Keyboard Control... -
Page 6: Features
1.1 Features This keyboard controller is capable to control 32 FastraxII dome cameras and remote control functions for variety of external switching devices like Multiplexer(max 255), Digital Video Recorder(max 99) etc… The keyboard controller features: • The capability of control a camera’s panning and tilting movement with variable speed from 0.5 °/sec to 90°/sec as well as its zoom, focus, and iris command. -
Page 7: Unpacking
1.2 Unpacking Unpack the equipment and make sure all listed items are included in the box. Contents of Keyboard box Keyboard controller ------------------------------- 1 Junction box --------------------------------------- 1 3m cable -------------------------------------------- 2 M4 Self tapping screws ------------------------- 4 Instruction manual --------------------------------- 1 12VDC SMPS -------------------------------------- 1... -
Page 8: Installation
2.1 Connection Diagram 2.1.1 Basic Installation Diagram POWER AC 24V AWG # 24 SENSOR ALARM INPUT UP TO 8 Chapter 2 INSTALLATION SIREN POWER AC 24V LIGHT ALARM OUTPUT UP TO 4 ALARM INPUT COM1 ALARM OUTPUT COM2 MONITOR Figure 2 – Basic installation diagram RS-485 HALF DUPLEX MODE : TX+,TX- ALARM INPUT... - Page 9 2.1.2 Single Multiplexer POWER POWER AC 24V AC 24V AWG # SPOT MONITOR MULTIPLEXER Figure 3 – Single Multiplexer POWER AC 24V COM1 COM3 COM2 COM4 (RS-422) MAIN MONITOR RS-485(+) PIN No.4 RS-485(-) PIN No.5...
-
Page 10: Single User With Two Multiplexer
2.1.3 Single User with Two Multiplexer POWER AC 24V AWG # 24 1ST MAIN MONITOR 1ST MULTIPLEXER POWER POWER AC 24V AC 24V COM1 COM2 (RS-422) SPOT MONITOR 2ND MULTIPLEXER RS-485(+) PIN No.4 RS-485(-) PIN No.5 Spot output of the first multiplexer to be connected to 16 multiplexer. -
Page 11: Two Multiplexer With Slave Keyboard Controller
2.1.4 Two Multiplexer with Slave Keyboard Controller POWER AC 24V AWG # 24 1ST MAIN MONITOR 1ST MULTIPLEXER Spot output 1 of the first multiplexer to be connected to 16 n: User, Spot out of n out of the 2 multiplexer to be connected to the n picture of the selected camera (1~(31-n)) on n No.+Cam. -
Page 12: Dip Switch Setting
2.2 Termination & Dip Switch Setting The first and last devices in an installation (dome and keyboard controller) must have the data line terminated by setting the DIP switch. Without proper termination, there is potential for control signal errors. Total length of the cable for communication should not exceed 1 mile. Refer to Figure 7 for setting the dome camera and keyboard controller termination. -
Page 13: Multiplexer Control
Multi- DOME plexer Termination 2.3 Multiplexer Control Duplex setup: NOTE: Multiplexers require a new ROM version to be controlled by the keyboard controller. The new multiplexer ROM accepts control instructions from the keyboard controller. If your multiplexer’s serial number is M104xxxx or higher, then it is ready to accept control instructions. Alternately, you can check the status of your multiplexer by pressing the Menu key of the multiplexer and then selecting item 9. -
Page 14: Keyboard Setup
Unit address: Protocol: 2.4 Keyboard Setup User need to setup network, passwords and special functions such as Uploading and Downloading programmed data from the dome cameras. To enter the Keyboard menu, press Ctrl + Menu. You will see the following menu. Joystick Up/Down scrolls menu items, push the stick to Right to enter the sub-menu. Configuration Network Data Bank... - Page 15 Com Ports Select the device to be connected on selected port. Dome : None/Dome … : None/DUPLEX/TRIPLEX/AUX IN/AUX I/O… DVR485 : None/ADR/SDR/IDR/AUX IN/AUX I/O… DVR232 : None/ADR/SDR/IDR/AUX IN/AUX I/O… Save and Exit Save the programmed data and return to the previous Menu (Exit without saving if you press ESC key) Note) AUX IN : auxiliary signal input ( simplex mode) AUX I/O : when auxiliary signal input , respond to the signal (Half duplex mode)
-
Page 16: Install With Adr Series
CAM:000 3. P ress Ctrl + Menu. Set the Slave ID to 01 4. Set Slave Node to “B” in case that master keyboard model is KBD-927(N : NTSC,P : PAL) Slave ID = 1 Slave Node : A/B ← A : KBD-927 2.5 Install with ADR series... - Page 17 A. Switch the keyboard controller ON B. Input password (Factory setting is 9999) C. Open the menu of the keyboard controller by pressing Ctrl + Main Key. D. Set as below in Network menu. Set Baud Rate Dome 9600 9600 DVR485 : 9600 DVR232 :...
- Page 18 Select “Camera” on the Device menu. Unit ID should be 1 up to 99. Unit ID is not allowed number “0”. Set “PTZ Device” and “ID” of the dome camera. Select RS232/RS485 after PTZ is installed, and then set-up as below table.
-
Page 19: Install With Sdr Series
RS232/RS485 Baud Rate RS232 9600 RS485 9600 5) After setting Unit ID, Camera, and RS232/RS485, installing dome camera is basically completed. Please refer to the manual of ADR for the other installation. 6) Press the related number of the controller which is correspondent to unit ID of ADR. Then press DVR button and adjust unit ID of the controller Make sure if any change is appeared on screen when you press basic testing. - Page 20 D. Set as below in Network menu. Set Baud Rate Dome 9600 9600 DVR485 : 9600 DVR232 : 9600 Com Ports Dome Dome None DVR485 : AUX IN DVR232 : SDR 4) How to setup SDR Switch the SDR on. Press the Menu button.
- Page 21 Select Camera of Device menu on the above menu. PTZ set up on the above Setup menu Select TEXT IN/PTZ after PTZ is installed, and then set-up as below RS232/TEXT IN Baud Rate RS232 9600 TEXT IN/PTZ 9600 1) After installing Camera, and RS232 & TEXT IN/PTZ setup, the installation with dome camera is basically completed.
-
Page 22: Install With Idr Series
2.7 Install with IDR series 22 AWG UTP CABLE J-BOX(FRONT) If user wants to connect with IDR, please proceed as the following order. 1) Connect RS-232C cable between RS-232C Port of IDR and DVR port of the J-box. ( This connection enables IDR control remotely from KBD controller) 2) Plug the RS-232C TO RS-485 converter in the RS-232C Port of IDR. - Page 23 Switch the IDR on. If press setup button on the above screen, the below screen will be appeared. Select camera input number that dome camera connected. Then install as below to select set-up PTZ after checking PTZ box. Port : COM2 RX Device : Fastrax….
- Page 24 If PTZ is not necessary for IDR, cable and installation here is not needed. (IDR is able to be controlled remotely and there’s no PTZ function) 8) How to IDR Remote setup - If selects Setup on main menu, the below screen will be appeared. After selecting System and checking Remote control box, please install as below to select Setup remote control.
-
Page 25: Chapter 3.0 Operation
3.1 Keyboard Lock/Unlock When the user leaves the control desk, he may wish to lock the keyboard controller to prevent unauthorized use. Pressing 777 + Enter will lock the keyboard controller. Pressing 777 + Enter while the keyboard is locked will open the password screen. - Page 26 Select cameras 1 to 16 by pressing the camera number and then Main. The selected camera will appear in the full screen mode and is under control if it was dome camera. Even if no camera is connected to the multiplexer input, the screen will show the camera input (see following example).
-
Page 27: Summary Of Keyboard Control
2) to the spot output of multiplexer 2 and the keyboard controller has control of the selected camera. 31+Cam = camera 15 of the second multiplexer. 3.3 Summary of Keyboard Controls IDR CONTROL MULTIPLEXER DVR CONTROL C am :001E ZOOM WIDE IRIS CLOSE FOCUS NEAR Figure 12 –... -
Page 28: Keys For Dome Camera
Key operation example Ctrl + Menu : Press and hold down Ctrl Key and press Menu Key 1 + Cam : Press 1 Key, Cam Key sequentially Ctrl + Joystick : Press and hold down Ctrl Key while manipulate Joystick Handle Enter + Joystick : Press and hold down Enter Key while manipulate Joystick Handle 3.3.1 Keys for Dome camera Function... -
Page 29: Keys For Multiplexer
Manual Focus Manual Iris Zoom Twist Up / Down Left / Right Joystick Press(Toggle) 3.3.2 Keys for Multiplexer Function Key Label 2 by 2 Display 3 by 3 Display 4 by 4 Display L.REC MACRO Select or Alarm Freeze Digital Zoom ZOOM Sequence Spot output... -
Page 30: Keys For Dvr
3.3.3 Keys for DVR Function Key Label Id Selection Play/Pause Rewind Fast Forward Stop/Preset Save Record/Preset Call Menu Alarm Freeze Search Sequence Display Mode Enter Display Mode CTRL+1-7,9 Go last CTRL + Go First CTRL + X times Backward No.+ play Descriptions DVR ID Selection. - Page 31 X times Forward No.+ Fast rewind at x(1~8) times speed in IDR play The Shuttle Ring only functions in the Playback mode. Turning the ring CTRL+ENTR+ Shuttle ring clockwise plays video forward. Turning the ring counterclockwise plays Joystick video backward. The Jog Dial only functions when playback video has been paused.
-
Page 32: Appendix A Trouble Shooting
If problems occur, verify the installation of the camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. Problem Joystick can’t control system. -
Page 33: Appendix B Specification
Baud Rates Operating Temperature Humidity Storage temperature Dimension Weight Communication (Design and Product specifications subject to change without notice) KEYBOARD CONTROLLER SPECO TECHNOLOGIES Appendix B SPECIFICATION 12VDC, 0.5W RS-485, RS-232C 2400~230K bps 0°C to 50°C(32 F to 122 0 to 90%RH(non-condensing) -20°C to 60°C(-40...
