Page 1: Instruction Manual
SPECO TECHNOLOGIES CVC-927PTZ DOME CAMERA Instruction Manual Please read this manual thoroughly before use and keep it handy for future reference. Rev.040812... -
Page 2: Explanation Of Graphical Symbols
Warnings and Cautions WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 4: Important Safeguards
IMPORTANT SAFEGUARDS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. -
Page 5: Table Of Contents
Table of Contents Chapter 1 — Introduction ...1 1.1 Features...1 Chapter 2 — Installation and Configuration ...3 2.1 Package Contents ...3 2.2 Basic Configuration Of Fastrax II E Dome Camera System ...4 2.3 Setting Dome Camera Termination...5 2.4 Setting Dome Camera Address(Id) ...7 2.5 Setting Dome Camera Protocol ...8 2.6 Connection ...9 Connecting to the RS-485 ... - Page 6 3.7 Tour ...15 3.8 Pattern ...17 3.9 Alarm...18 3.10 Area Title...18 3.11 Privacy Zone ...19 3.12 Camera –HID2404SXEXXX MODEL Focus Control ... 21 WB(White Balance) Control... 22 AE Control ... 22 Line Lock Control ... 23 Night Shot Menu... 23 3.13 Camera –HID2404HCEXXX MODEL Focus Control ...
- Page 7 Dome Reset ... 30 System Information ... 30 Appendix A — Specifications...31 Appendix B — Troubleshooting...34 Appendix C — Glossary ...35 Appendix D — Short Cut Key...38...
-
Page 8: Chapter 1 - Introduction
Chapter 1 — Introduction 1.1 Features The Fastrax II E dome camera and the Fastrax II Keyboard Controller make up the building blocks for any surveillance/security system. Using multiple Keyboard Controllers and multiple dome cameras, no place is too large for monitoring. Extensible and flexible architecture facilitates remote control functions for a variety of external switching devices such as multiplexers and DVRs. - Page 9 Alarm Input UP TO 8 <Sensor> <Siren> Alarm Output UP TO 4 <Flashing Light> UP TO 32 CAMERA Figure 1 – Typical System Configuration push remove window Note : It is recommended to remove camera window for improving picture quality when you use bubble ring ass’y.
-
Page 10: Chapter 2 - Installation And Configuration
Chapter 2 — Installation and Configuration 2.1 Package Contents The package contains the following. Fastrax II E (Dome Camera) Bubble Ring Instruction Manual (This Document) Assembly Screws for Attaching Fastrax II E Plastic Anchor 10Pin Connector 12Pin Connector CAUTION: Be sure to have caution labels( of the camera. -
Page 11: Basic Configuration Of Fastrax Ii E Dome Camera System
2.2 Basic Configuration of Fastrax II E Dome Camera System. POWER AC 24V STP AWG # 22 SENSOR ALARM INPUT UP TO 8 SIREN POWER AC 24V LIGHT ALARM OUTPUT UP TO 4 ALARM INPUT COM1 ALARM OUTPUT COM2 MONITOR Figure 4–... -
Page 12: Setting Dome Camera Termination
The dome camera must be installed by qualified service personnel in accordance with all local and federal electrical and building codes. The system should be installed according to Figures 4 through 9. Termination Switches KSD02H Address(ID) and Protocol selection Switches 2.3 Setting Dome Camera Termination The device which is connected at end of line, whether it be a dome camera or keyboard controller, must have the cable for communication terminated by setting the appropriate DIP... - Page 13 Figure 7- Termination Diagram...
-
Page 14: Setting Dome Camera Address(Id)
2.4 Setting Dome Camera Address (ID) To prevent damage, each dome camera must have a unique address (ID). When installing multiple dome cameras using a multiplexer, it is suggested that the dome camera address match the multiplexer port number. If you want to set the address more than 999, you should contact the service provider. Example: Port 1 = Dome 1, Port 2 = Dome 2 …... -
Page 15: Setting Dome Camera Protocol
2.5 Setting Dome Camera Protocol If a dome camera is to be installed with a Fastrax keyboard controller, select F2 protocol. Consult service personnel if a dome camera is installed with device other than a keyboard controller. NTSC Camera Baud rate Protocol RS-422/ RS-485... -
Page 16: Connection
2.6 Connections • Connecting to the RS485/ 422 The dome camera can be controlled remotely by an external device or control system, such as a control keyboard, using RS485 half-duplex , RS422 duplex or simplex serial communications signals. Connect Marked Rx+, Rx- to Tx+ and Tx- of the RS485 control system. If control system is RS422, connect Rx+(Tx+), Rx+(Tx-) and Rx+, Rx- of the dome camera to Tx+, Tx- and Rx+, Rx- of the control device respectively. - Page 17 PRESET No. 001 PRESET PRESET TITLE or AREA TITLE INFORMATION DISPLAY FUNCTION T001 UNDER RUNNING ALARM:1 ALARM DISPLAY RAM TEST CHECK NO. : OK! CHECK AAAA : OK! CHECK 5555 : OK! FASTRAX II E Vx.xxx CAMERA TYPE xxxx WAIT DOME SETTING. INIT TILT ORGIN SET OK INIT PAN ORGIN SET OK INIT CAMERA SET OK...
-
Page 18: Chapter 3 - Program And Operation
Chapter 3 — Program and Operation 3.1 Dome Camera Selection Before you program or operate a dome camera, you must select the dome camera by pressing the dome camera No. + CAM Example: Pressing 1 , 0 and CAM key sequentially will select dome camera 10. The selected dome camera ID will be displayed on the LCD monitor of the keyboard controller. -
Page 19: How To Control On-Screen Menu Utility
3.3 How to control the On-Screen Menu Utility Action MENU Joystick left or right Joystick up or down Joystick down Zoom handle twist CTRL + Joystick 3.4 Auto Scan (First Item of the Main menu / Shortcut: SCAN ) The Auto scan supports up to 8 programmed angles at user-programmable speeds. Follow these steps to program Auto Scan: SCAN 01 SPEED(MODE) : FAST VECTOR... - Page 20 1. Press the SCAN key to enter Auto Scan menu directly. Or press the MENU key to display the main menu on the monitor. Scroll to Auto Scan and push the Joystick to the right. 2. Select an Auto Scan number by pushing the Joystick left or right. 3.
-
Page 21: Preset
3.5 Preset (Second Item of the Main menu / Shortcut: PRST ) If you need to view specific places routinely, you should program presets. A preset is a programmed video scene with automatic pan, tilt, zoom, focus and iris settings. Once programmed, entering the number and pressing a Preset button on your controller automatically calls up the preset. -
Page 22: Shortcut Preset Program
5. After aiming the camera (view direction and lens control), release CTRL/PGM . Then twist the Joystick handle or Press Tele or Wide Key to store the selected view. The position number will be displayed and the user will be prompted to enter a preset title. 6. - Page 23 Tour2 executes as follows: Preset3 Preset4 (Tour4 is still valid if called directly from Tour2.) TOUR 01:xxxxxxxxxxxxxxxx SCAN TYPE:NORMAL === === 003 === === === === A08 === === === === === === === T02 === 001 === === === === === === T08 === === === === === === === === === === === === === === === === ===...
-
Page 24: Pattern
through the alphanumeric characters. Push the handle to the right or left to select the next or previous digit. 9. Select Save and Exit by pushing the Joystick to the right. Press ESC to exit the program without saving. NOTE: Press the Home key at a programmed position to delete programmed function. In the Tour mode, in conjunction with preset and Auto Scan, you can make the camera travel from a preset position to another preset position at a specific speed. -
Page 25: Alarm
7. Pressing ESC will not save your information and exits to the previous mode. Press the HOME key at any programmed position to delete that programmed pattern. NOTE: If total recording time reaches 240 seconds, it will automatically stop for a moment and restart recording. -
Page 26: Area Title
3.10 Area Title (Sixth Item of Main menu) Enter a specific name on programmed angle between START and END. For the screen below, when the camera points at an angle between 124.3 ° to 359.5 ° , ABC will be displayed on the screen. -
Page 27: Privacy Zone
3.11 Privacy Zone (Seventh Item of Main menu) Hide up to 8 unwanted views in a camera. 01 xxxxxxxxxxxxxxxx 02 xxxxxxxxxxxxxxxx 03 xxxxxxxxxxxxxxxx 04 xxxxxxxxxxxxxxxx 05 xxxxxxxxxxxxxxxx 06 xxxxxxxxxxxxxxxx 07 xxxxxxxxxxxxxxxx 08 xxxxxxxxxxxxxxxx SAVE AND EXIT(ESC TO CANCEL) 1. Press MENU to display the main menu on the monitor. Select the Privacy Zone option by pushing Joystick Up or Down and push to right to enter the detail menu. -
Page 28: Camera -Hid2404Sxexxx Model
3.12 Camera (Eighth Item of Main menu) NOTE: The menu features will vary depending on the camera module installed in your dome camera. FOCUS CONTROL WB CONTROL AE CONTROL LINE LOCK CONTROL SHARPNESS BACK LIGHT DIGITAL ZOOM NIGHT SHOT CONTROL (optional) SAVE AND EXIT(ESC TO CANCEL) SHARPNESS The higher the value,the more edges in the picture will be enhanced(0~15) -
Page 29: Wb(White Balance) Control
• WB (white balance) CONTROL MODE R GAIN : B GAIN : EXIT(ESC TO EXIT) MODE MANUAL / AUTO / INDOOR / OUTDOOR / ONE PUSH / ATW RGAIN 0 ~ 255 BGAIN 0 ~ 255 Use the ATW mode for normal use. RGAIN / BGAIN modes are controllable only in MANUAL Mode Push the Joystick to the right or left to change. -
Page 30: Line Lock Control
• LINE LOCK CONTROL MODE PHASE EXIT(ESC TO EXIT) MODE INTERNAL / EXTERNAL PHASE 0~255 EXIT (ESC TO EXIT) • NIGHT SHOT MENU The NIGHT SHOT option removes the IR cutoff filter of the camera and makes the camera sensitive to near infrared. The picture will appear greenish. This may be suppressed by setting the BLACK &... -
Page 31: Camera -Hid2404Hcexxx Model
3.13 Camera (Eighth Item of Main menu) NOTE: The menu features will vary depending on the camera module installed in your dome camera. FOCUS CONTROL WB CONTROL AE CONTROL LINE LOCK CONTROL SHARPNESS : 32 BACK LIGHT DIGITAL ZOOM NIGHT SHOT CONTROL SAVE AND EXIT(ESC TO CANCEL) SHARPNESS The higher the value, the more edges in the picture will be enhanced... -
Page 32: Wb(White Balance) Control
• WB (white balance) CONTROL MODE R GAIN : B GAIN : EXIT(ESC TO EXIT) MODE MANUAL / AUTO RGAIN 0 ~ 255 BGAIN 0 ~ 255 Use the AUTO mode for normal use. RGAIN / BGAIN modes are controllable only in MANUAL Mode Push the Joystick to the right or left to change. -
Page 33: Line Lock Control
• LINE LOCK CONTROL MODE INTERNAL / EXTERNAL PHASE 0~255 EXIT (ESC TO EXIT) • NIGHT SHOT MENU The NIGHT SHOT option removes the IR cutoff filter of the camera and makes the camera sensitive to near infrared. The picture will appear greenish. This may be suppressed by setting the BLACK &... -
Page 34: Dome Setup
3.14 Dome Setup (Ninth Item of Main menu) • HOME FUNCTION SETUP After a dome control menu item has been selected, follow the directions below to set the function. HOME FUNCTION FUNCTION NUMBER : --- WATING TIME FUNCTION ENABLE : OFF SAVE AND EXIT(ESC TO CANCEL) HOME FUNCTION FUNCTION NUMBER... -
Page 35: Osd Display Setup
• OSD DISPLAY CAMERA TITLE VIEW DIRECTION DOME OSD DISPLAY : ON AREA DISPLAY SAVE AND EXIT(ESC TO CAMERA TITLE VIEW DIRECTION DOME OSD DISPLAY AREA DISPLAY • VIEW DIRECTION “ON” sets current direction as N(north) and the coordinate angle to 000. “OFF” hides the directional title. -
Page 36: Panning Range
• PANNING RANGE When the dome camera is installed near a wall, panning range can be limited by user. RIGHT LIMIT : 000.0 LEFT LIMIT ENABLE SWAP RIGHT/LEFT SAVE AND EXIT(ESC TO CANCEL) • FLIP Allows the dome camera to automatically turn 180 degrees when the camera tilts to its lower position. -
Page 37: Origin Offset
Erase all stored data from the Flash-ROM of the selected dome camera. You will be asked to enter Yes or No. If you intend to erase all data then press the MENU key, otherwise press the ESC key to exit without erasing. The erased data includes all stored data (titles, presets, and tours….) except origin offset. -
Page 38: Appendix A - Specifications
Appendix A — Specifications Camera(HID2404SLExxx) Image Sensor Picture elements Horizontal Resolution Lens View angle Minimum Illumination S/N ratio Camera(HID2404SMExxx) Image Sensor Picture elements Horizontal Resolution Lens View angle Minimum Illumination S/N ratio Camera(HID2404SHExxx) Image Sensor Picture elements Horizontal Resolution Lens 1/4"... - Page 39 View angle Minimum Illumination S/N ratio Image stabilizer Camera(HID2404HCExxx) Image Sensor Picture elements Horizontal Resolution Lens View angle Minimum Illumination S/N ratio Approx. 45 ° (WIDE end) to 2 ° (TELE end) 2.5 lux(F1.4,normal shutter speed) 0.2 lux (F1.4,1/4S(NTSC) OR 1/3S(PAL) 0.01 lux (1/4s with IR Cut Filter Removed) more than 49Db ON/OFF...
- Page 40 General Certification CE EMC, FCC CLASS A, UL Electrical Input Voltage 18 to 30 VAC; 24 VAC nominal, built-in power-line surge Power Requirement 24 VAC/VDC 850mA Power Consumption Maximum 20W Alarm Output 4 Normal relays 24 VDC/1A Max (selectable NC/NO) Alarm Input 8 Normal dry contact (selectable NC/NO) Control...
-
Page 41: Appendix B - Troubleshooting
Appendix B — Troubleshooting If problems occur, verify the installation of the camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. Problem No video. -
Page 42: Appendix C - Glossary
Appendix C — Glossary Alarm Actions The assigned responses for the dome camera when inputs change from normal to abnormal states. The dome may run a Preset, Pattern, or have no assigned action for each of the four dome inputs. The dome may also send alarm states to the host controller for processing. See also Input and Normal Input State. -
Page 43: Line Lock
IR Mode A feature of the camera that permits manual or automatic switching between color and IR (black-and-white) operation. When IR mode is active, clearer images may be obtained under low-light conditions. Line Lock Allows you to phase lock the video with the AC power line. When line lock is enabled, it prevents vertical video rolling when switching multiple cameras to a single monitor. -
Page 44: Privacy Zones
Privacy Zones Masked areas of the dome camera's viewing area. These masks prevent operators of the surveillance system from viewing these designated zones. The Privacy Zones move in relation to the dome camera’s pan/tilt position. In addition, the apparent size of the Privacy Zone adjusts automatically as the lens zooms in or out. -
Page 45: Appendix D - Short Cut Key
Appendix D — Short Cut Key Short Cut Key Function PRST Pop up preset setup menu. TOUR Pop up guard Tour setup menu. PTRN Pop up Pattern setup menu. SCAN Pop up Auto Scan setup menu. NO.+ PGM + PRST Store the current view at the selected number. - Page 46 SPECODOME CAMERA 040705...
