Remove Measurement Readouts
Changing the Measurement Reference Levels
TLS 216 User Manual
Figure 1-18: Four Simultaneous Measurement Readouts
The Measure menu lets you remove measurements you no longer want dis-
played. You can remove any one measurement, or you can remove them all at
once.
Press MEASURE Remove Measrmnt (main)
ment 2, and Measurement 4 (side) to remove those measurements. Leave the
rise time measurement displayed.
By default, the measurement system will use the 10% and 90% levels of the
waveform for taking the rise time measurement. You can change these values to
other percentages or change them to absolute voltage levels.
To examine the current values, press Reference Levels (main)
(side).
Example 3: Taking Measurements Automatically
Press here to remove
menus from screen.
Measurement 1, Measure-
High Ref
1–25
