Triggering on Signals
Force a Trigger
Trigger a Single Sequence
To Determine Trigger Status
Monitor the Trigger
Status Lights
3–160
threshold level to trigger on a waveform edge. As previously stated, these two
controls also work with pulse triggering.
To force the logic scope to immediately start acquiring a waveform, even without
a trigger event occurring, press the FORCE TRIG front-panel button. (See
Figure 3-72.) Use FORCE TRIG with any of the five trigger types.
When in Normal trigger mode, use FORCE TRIG to quickly determine if there
is a signal present for the logic scope to acquire. Once signal presence is
established, you can determine how to trigger on it (press SET LEVEL TO 50%,
check trigger source setting, and so on).
The logic scope forces acquisition even when you press FORCE TRIG before the
end of pretrigger holdoff. However, pressing FORCE TRIG does not restart the
acquisition system when stopped (for instance, by pressing the RUN/STOP
button).
To trigger on the next valid trigger event and then stop, press SHIFT
SINGLE TRIG. Now press the RUN/STOP button each time you want to
initiate a single sequence of acquisitions. Use SINGLE TRIG with any of the
five trigger types.
To leave Single Trig mode, press SHIFT
(main) RUN/STOP Button Only (side).
Read the description under Set Stop After Mode on page 3–20 for further
information on single sequence acquisitions.
To quickly determine partial trigger status (for instance, if the logic scope is
triggered, its trigger type, and the type of trigger selected), use the trigger status
lights and the trigger readout.
To determine the state of the trigger circuitry, watch the three status lights in the
Trigger control area. (See Figure 3-72.) The lights are labeled TRIG'D, READY,
and ARM. Use the trigger status lights with any of the five trigger types.
When TRIG'D lights, it means the logic scope has recognized a valid trigger and
is filling the posttrigger portion of the waveform.
When READY lights, it means the logic scope can accept a valid trigger event
and it is waiting for that event to occur.
When ARM lights, it means the trigger circuitry is filling the pretrigger portion
of the waveform record.
ACQUIRE MENU Stop After
