Summary of Contents for Tektronix TLA700 Series

  • Page 1 T h e t e s t & me a s u r e me n t e q u i p me n t y o u n e e d a t t h e p r i c e y o u w a n t . A l l t e s t I n s t r u me n t s , I n c .
  • Page 2 Installation Manual TLA700 Series Logic Analyzer 071-1235-01 Warning The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to performing service.
  • Page 3 Copyright © Tektronix, Inc. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and are protected by United States copyright laws and international treaty provisions. Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the...
  • Page 4 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located.
  • Page 5 SOFTWARE WARRANTY Tektronix warrants that the media on which this software product is furnished and the encoding of the programs on the media will be free from defects in materials and workmanship for a period of three (3) months from the date of shipment.
  • Page 6: Table Of Contents

    ......... . . Connecting Accessories to the TLA700 Series .
  • Page 7 ......... . . TLA700 Series Logic Analyzer Installation Manual...
  • Page 8 ..........Figure 10: TLA700 series accessories connections .
  • Page 9 Figure 26: TLA715 Portable mainframe front panel ... . . Figure 27: TLA700 series external connectors ....
  • Page 10: General Safety Summary

    Do Not Operate in Wet/Damp Conditions. Do Not Operate in an Explosive Atmosphere. Keep Product Surfaces Clean and Dry. Provide Proper Ventilation. Refer to the manual’s installation instructions for details on installing the product so it has proper ventilation. TLA700 Series Logic Analyzer Installation Manual...
  • Page 11 CAUTION indicates a hazard to property including the product. Symbols on the Product. The following symbols may appear on the product: CAUTION WARNING Protective Ground Refer to Manual High Voltage (Earth) Terminal Mains Disconnected Mains Connected Standby OFF (Power) ON (Power) TLA700 Series Logic Analyzer Installation Manual...
  • Page 12: Service Safety Summary

    Use Care When Servicing With Power On. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components. To avoid electric shock, do not touch exposed connections. TLA700 Series Logic Analyzer Installation Manual...
  • Page 13 Service Safety Summary viii TLA700 Series Logic Analyzer Installation Manual...
  • Page 14: Preface

    Be sure to follow all warnings, cautions, and notes in this manual. TLA700 Series Logic Analyzers The TLA700 series logic analyzers are comprised of a portable mainframe, benchtop mainframe, expansion mainframe (Figure i and Figure ii), and all of the accessories and supports that can be used with them.
  • Page 15: Figure Ii: Tla721 Benchtop Mainframe With A Tla7Xm Expansion Mainframe

    For a complete list of accessories, refer to the online help. Expansion mainframe Benchtop mainframe Figure ii: TLA721 Benchtop Mainframe with a TLA7XM Expansion Mainframe TLA700 Series Logic Analyzer Installation Manual...
  • Page 16: Related Documentation

    TLA5Fxx, TLA6Fxx, & TLA7Fxx PowerFlex Upgrade Kit Instructions TLA7PG2 Pattern Generator Module Instructions Documents available only as PDF files on the documentation CD and downloadable from the Tektronix website. TLA Series Product Specifications Tektronix Logic Analyzer Programmatic Interface (TPI.net) tektronix.com...
  • Page 17: Contacting Tektronix

    This phone number is toll free in North America. After office hours, please leave a voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix web site for a list of offices. TLA700 Series Logic Analyzer Installation Manual...
  • Page 18: Basic Installation

    Basic Installation This chapter describes all of the steps needed to install your Tektronix logic analyzer and its related accessories. It is written from the perspective that you purchased most of the items uninstalled and you intend to install all of the pieces.
  • Page 19: Tla715 Portable Mainframe Site Considerations

    CAUTION. Verify that all mainframes are powered off before continuing the installation procedure. If you are installing more than two expansion main- frames, always use a rackmount kit. Contact your local Tektronix representative for information on site considerations for multiple mainframes.
  • Page 20: Figure 1: Tla721 Benchtop Mainframe With One Tla7Xm Expansion Mainframe

    3. Use a screwdriver to tighten the retaining screws (maximum of 2.5 in-lbs). Benchtop mainframe Expansion mainframe Figure 1: TLA721 Benchtop Mainframe with one TLA7XM Expansion Mainframe. 4. Place the EXPANSION 1 label in the outlined area on the upper right side of the expansion mainframe. TLA700 Series Logic Analyzer Installation Manual...
  • Page 21: Figure 2: Tla721 Benchtop Mainframe With Two Tla7Xm Expansion Mainframes

    Expansion mainframe Expansion mainframe TLA721 Benchtop Mainframe Figure 2: TLA721 Benchtop Mainframe with two TLA7XM Expansion Mainframes Expansion mainframe Expansion mainframe TLA715 Portable Mainframe Figure 3: TLA715 Portable Mainframe with two TLA7XM Expansion Mainframes TLA700 Series Logic Analyzer Installation Manual...
  • Page 22: Install The Expansion Cables

    A of the expansion module on the TLA721 Benchtop Mainframe or TLA715 Portable Mainframe side. 8. Fasten the expansion cable connector to the expansion module by tightening the two hold-down screws. TLA700 Series Logic Analyzer Installation Manual...
  • Page 23: Chassis Ground Connections

    Chassis ground Safety ground screw (TLA721 Benchtop mainframe only) Figure 4: Location of the ground connection on the TLA700 logic analyzers TLA700 Series Logic Analyzer Installation Manual...
  • Page 24: Installing Tla700 Modules

    FF, you must verify that no two modules (or devices) share the same address. NOTE. Do not set any module to logical address 00. Logical address 00 is reserved exclusively for the controller. TLA700 Series Logic Analyzer Installation Manual...
  • Page 25: Merging Modules

    1- -2, and the logic analyzer module in slots 3- -4. Use a screwdriver to tighten the retaining screws to 2.5 in-lbs after seating the modules in place. See Figure 6 on page 10. TLA700 Series Logic Analyzer Installation Manual...
  • Page 26: Mainframe

    5- -6. Place double-width slot covers over slots 7- -8, 9- -10, and 11- -12. Use a screwdriver to tighten the retaining screws to 2.5 in-lbs after seating the modules in place. See Figure 6. TLA700 Series Logic Analyzer Installation Manual...
  • Page 27: Figure 6: Installing Modules

    Basic Installation Portable mainframe Benchtop mainframe Retaining screws Injector/ejector handles Figure 6: Installing modules TLA700 Series Logic Analyzer Installation Manual...
  • Page 28: Module Keys

    Figure 7. Key Conflict TLA7XM TLA7XM TLA7Nx TLA721 Expansion Module Expansion Module Logic Analyzer Module Benchtop Controller TLA7Dx TLA7XM TLA7XM TLA7Nx Oscilloscope Module Expansion Module Expansion Module Logic Analyzer Module Figure 7: Module keys TLA700 Series Logic Analyzer Installation Manual...
  • Page 29: Covering Empty Slots

    If you have any unused (empty) slots in your mainframe, install blank-slot panel covers to meet EMC and cooling specifications. Install a blank-slot panel cover for each empty slot as shown in Figure 8 or 9. Use only Tektronix TLA covers; otherwise the mainframe may not meet EMC and cooling requirements.
  • Page 30: Connecting Accessories

    The connection points are shown in Figure 10. Use the icons that appear in the to the TLA700 Series circled areas as a guide. Icon Description Primary video Secondary video RS-232 Printer Mouse Keyboard Floppy disk drive PC card (LAN or other) Figure 10: TLA700 series accessories connections TLA700 Series Logic Analyzer Installation Manual...
  • Page 31: Additional Accessory Connection Information

    First slightly tighten screws, then snug each screw to 4 in-lbs (max). Under tightening the probe screws can result in intermittence. Over tightening can result in stripped screws. TLA700 Series Logic Analyzer Installation Manual...
  • Page 32: Connecting Probes To The Logic Analyzer Module

    Logic Analyzer Module Probe Match color- - coded labels Figure 11: Connecting the P68xx or P69xx logic analyzer probes to the TLA7NAx logic analyzer module The P69xx probes are also compatible with TLA7Axx logic analyzer modules. TLA700 Series Logic Analyzer Installation Manual...
  • Page 33: Figure 12: Connecting The P68Xx Or P69Xx Logic Analyzer Probes To The Tla7Axx Logic Analyzer Module

    Basic Installation Probe Match color- - coded labels Figure 12: Connecting the P68xx or P69xx logic analyzer probes to the TLA7Axx logic analyzer module P68xx probes are also compatible with TLA7NAx logic analyzer modules. TLA700 Series Logic Analyzer Installation Manual...
  • Page 34: Configuring And Connecting The Pattern Generator Probes

    TLA7PG2 Probe Instruction Manual for information about how to change the series termination resistors. Always power down the logic analyzer before connecting the pattern generator probes to the logic analyzer and to the target system. TLA700 Series Logic Analyzer Installation Manual...
  • Page 35: First Time Operation

    1. Check that the line fuse is correct for your application. See Table 2. 2. Connect the power cord. See Figure 14 on page 19. 3. If you have an external monitor, connect the power cord and turn on the monitor. Table 2: TLA700 series line fuses Line voltage Rating Tektronix part number...
  • Page 36: Figure 14: Line Fuse And Power Cord Connector Locations

    Mainframe for further information. 4. Press the On/Standby switch to turn on the mainframe (see Figure 15 for the switch location). 5. Wait for the mainframe to complete the power-on self-tests and start Windows. TLA700 Series Logic Analyzer Installation Manual...
  • Page 37: Turning On The Tla7Xm Expansion Mainframes

    The power-on diagnostics check the basic functionality. The diagnos- tics run every time you turn on the logic analyzer. You can also verify more detailed functionality by running the self-calibration and extended diagnostics. TLA700 Series Logic Analyzer Installation Manual...
  • Page 38: Checking Logic Analyzer Probes (Optional)

    NOTE. If you connect probes to any channels other than the A2 and A3 groups, you must define channel groups containing those channels in the LA Setup window before you can view data from those channels in the Listing or Waveform windows. TLA700 Series Logic Analyzer Installation Manual...
  • Page 39: Checking The P624X Oscilloscope Probes (Optional)

    2. Remove the replaceable hard disk drive cartridge by depressing it to release the latch; see Figure 16 on page 23. 3. Pull on the replaceable hard disk drive cartridge to remove it from the chassis. TLA700 Series Logic Analyzer Installation Manual...
  • Page 40: Connecting Probes To The Target System

    For probe-specific connection details, refer to the appropriate probe instruction manual available on the TLA Documentation CD or the Tektronix Web site. TLA700 Series Logic Analyzer Installation Manual...
  • Page 41: Additional Information

    39. For detailed information on using the logic analyzer refer to the Tektronix Logic Analyzer Family User Manual or to the TLA online help. To access main online help, go to the Help menu or click the toolbar buttons shown: Click for Topic help.
  • Page 42: Merging Tla700 Modules

    Merging TLA700 Modules This chapter describes how to merge TLA700 series logic analyzer and pattern generator modules to form wider modules, that all operate from a single time base. A merged logic analyzer module set consists of a master logic analyzer module and up to four slave logic analyzer modules that are physically connected together by a merge cable and are merged in software.
  • Page 43: Tla7Pg2 Pattern Generator Module Merging Rules

    You must complete these steps prior to installing the modules in a mainframe. CAUTION. To avoid damaging the mainframe or any modules, always power off the mainframe before removing or installing modules. TLA700 Series Logic Analyzer Installation Manual...
  • Page 44: Merging Tla7Axx/Tla7Nax Logic Analyzer Modules

    TLA7Axx and TLA7NAx modules: 1. Place the module on the right side. 2. Using a Torx T-10 screwdriver, remove the two screws holding the merge connector to the module (see Figure 18). TLA700 Series Logic Analyzer Installation Manual...
  • Page 45: Figure 18: Removing The Merger Connector Assembly From The Module

    6. Place the first pair of modules to be merged side-by-side such that the merge connector assemblies line up and connect between the two modules (see Figure 19). 7. Push the two modules together until the connectors are seated in place. TLA700 Series Logic Analyzer Installation Manual...
  • Page 46: Figure 19: Connecting Modules In A Merged Set

    10. Align the tops and bottoms of the modules with the slots in the mainframe (see Figure 20 on page 30). You may need the help of another individual if your merged module set contains more than two modules. TLA700 Series Logic Analyzer Installation Manual...
  • Page 47: Figure 20: Installing The Merged Module Set In The Mainframe

    Latch in place Figure 20: Installing the merged module set in the mainframe 11. Slide the modules all the way into the mainframe until they rest against the rear panel connectors. TLA700 Series Logic Analyzer Installation Manual...
  • Page 48: Unmerging Tla7Axx/Tla7Nax Logic Analyzer Modules

    9. Install the two Torx T-10 screws onto the assembly and tighten the screws to 4 in-lbs. 10. Repeat steps 7 through 9 for the other modules. You can now reinstall the modules in the mainframe as needed. TLA700 Series Logic Analyzer Installation Manual...
  • Page 49: Merging Tla7Lx/Mx/Nx/Px/Qx Logic Analyzer Modules

    6. Remove the screws holding the merge cable bracket to the cover. 7. Remove the top part of the cable bracket and set it aside. 8. Remove the module cover and locate the merge cable. TLA700 Series Logic Analyzer Installation Manual...
  • Page 50: Figure 21: Removing The Cover

    9. Replace the cover while feeding the merge cable through the hole in the cover (see Figure 22). NOTE. Do not twist the cable while feeding it through the hole. If the cable is twisted, the modules will not merge correctly. TLA700 Series Logic Analyzer Installation Manual...
  • Page 51: Figure 22: Feeding The Merge Cable Through The Cover

    14 through 19. If the cover is not properly seated, the module can be damaged when you install it in the mainframe and it will not meet EMC requirements. TLA700 Series Logic Analyzer Installation Manual...
  • Page 52: Figure 23: Seating The Cover On The Chassis

    (two on the top and two on the bottom) to secure the cover to the chassis. 16. Install the screws near the front of the module. 17. Slide the rear panel on the chassis and install the rear panel screws. TLA700 Series Logic Analyzer Installation Manual...
  • Page 53: Figure 24: Lining Up The Two Modules

    22. Slide the modules all the way into the mainframe until they rest against the rear panel connectors. 23. Use the injector handles to firmly seat the modules in place one at a time. 24. Tighten the four retaining screws on each module to 2.5-in. lbs. TLA700 Series Logic Analyzer Installation Manual...
  • Page 54: Three-Way Logic Analyzer Merge Procedure

    3. Remove the screws from the side cover and rear cover. 4. Push the merge cable through the side cover and remove the cover. 5. Position the merge cable as shown in Figure 25. TLA700 Series Logic Analyzer Installation Manual...
  • Page 55 11. Install the merge cable bracket so that the guide pins point into the module. 12. Install and tighten the screws on the merge cable bracket. 13. Verify that you have installed and tightened all screws on the module. TLA700 Series Logic Analyzer Installation Manual...
  • Page 56: Product Overview

    H System Trigger In and System Trigger Out, used to receive or send a trigger from/to an external source. H External Signal In and External Signal Out, used to receive or send a signal from/to an external source. H Accessory connections. TLA700 Series Logic Analyzer Installation Manual...
  • Page 57 Secondary video Hard disk drive Primary video SYSTEM TRIG IN Mouse SYSTEM TRIG OUT EXTERNAL SIG IN Keyboard EXTERNAL SIG OUT LPT printer port TLA721 Benchtop mainframe (front view) Figure 27: TLA700 series external connectors TLA700 Series Logic Analyzer Installation Manual...
  • Page 58: Restoring And Reinstalling Software

    CD, or network drive) before continuing with this procedure. The Tektronix Logic Analyzer comes with a CD containing the Microsoft Windows operating system and the latest application software. The process of reloading the software on the hard disk will destroy any files or programs installed on the hard disk.
  • Page 59: Installing The Operating System And Tla Application Software

    Tektronix Account Manager to order a replacement copy. If you cannot contact the account manager, contact the Tektronix Support Center (refer to Contacting Tektronix on page xii at the beginning of this document). NOTE. You can reinstall the Microsoft Windows operating system and other software only from the Hard Disk Image CD that came with your instrument.
  • Page 60: Table 4: Bios Boot Settings For Reinstalling Software From The

    Table 4: Bios Boot settings for reinstalling software from the CD-ROM Instrument Setting TLA715 or TLA721 ATAPI CD-ROM Drive +Removable Devices +Hard Drive 4. Save the settings by pressing function key F10 and confirm that you want to save the new settings. TLA700 Series Logic Analyzer Installation Manual...
  • Page 61 9. Restore any user files that you backed up previously. Reinstall any software (such as the microprocessor support packages) that you want to use on the logic analyzer. 10. If desired, reconfigure the TLA network interface. TLA700 Series Logic Analyzer Installation Manual...
  • Page 62: Reinstalling The Tla Application Software And The Pattern Generator Application Software

    1. Log on to the instrument as Administrator and quit any applications. 2. Install Disc 1 of the Tektronix Logic Analyzer Family Application Software in the CD-ROM drive of the logic analyzer. 3. Click Run in the Windows Start menu to display the Run dialog box.
  • Page 63: Installing The Tpi Or Ppi Remote Operation Software

    PC. If you have an older version already installed on your PC, the program will automatically detect it and replace it during the upgrade process. 1. Install Disc 1 of the Tektronix Logic Analyzer Family Application Software in the CD-ROM drive of the PC.
  • Page 64: Installing The Tlavu And Patgenvu Software On A Pc

    Access the ReadMe file by selecting: Start → Programs → Tektronix Logic Analyzer → TLA Documenta- tion → TLAVu ReadMe or Start → Programs → Tektronix Pattern Generator → Pattern Generator Documentation → PatGenVu ReadMe.
  • Page 65: Upgrading Or Restoring Firmware

    If any modules indicate invalid or similar messages, you must update the firmware for those modules. 2. Exit the logic analyzer application. 3. Click Start → Programs → Tektronix Logic Analyzer → TLA Firmware Loader. 4. You may be prompted to cycle the power on the mainframe after completing the upgrade operation.
  • Page 66 16. Verify that the firmware version for the selected module matches the version on the label that you recorded in step 12. 17. If the firmware versions do not match, power down the mainframe, remove the module from the mainframe and update the label. TLA700 Series Logic Analyzer Installation Manual...
  • Page 67: Upgrading Firmware On Tla7Lx/Mx/Nx/Px/Qx/Dx/7Ex Modules

    8. Wait for the TLA application to start. NOTE. Any modules with the flash programming jumper installed will not display in the System window. 9. Exit the TLA application (and pattern generator application if you have it installed on your instrument). TLA700 Series Logic Analyzer Installation Manual...
  • Page 68 Restoring and Reinstalling Software Flash programming pins Figure 28: Flash programming pins 10. Click Start → Programs → Tektronix Logic Analyzer → TLA Firmware Loader. 11. Select the modules that you want to update from the list of modules displayed in the Supported list box near the top of the window. This selects the modules for the upgrade.
  • Page 69: Table 5: Tla Firmware Files

    Properties from the System menu. 23. Click the module tab (for example, LA1). 24. Verify that the firmware version for the selected module matches the version on the label that you recorded in step 20. TLA700 Series Logic Analyzer Installation Manual...
  • Page 70: Upgrading Firmware On The Tla7Pg2 Pattern Generator Modules

    System window. 9. Exit the pattern generator application (and the TLA application). 10. Click Start → Programs → Tektronix Logic Analyzer → TLA Firmware Loader. 11. Select the modules that you want to update from the list of modules displayed in the Supported list box near the top of the window.
  • Page 71 24. Verify that the firmware version for the selected module matches the version on the label that you recorded in step 20. 25. If the firmware versions do not match, power down the mainframe, remove the module from the mainframe and update the label. TLA700 Series Logic Analyzer Installation Manual...
  • Page 72: Appendix A: Tla721 Mainframe Power Information

    4. Refer to Figure 29 on page 57 to determine the proper power cord and line fuse for your mainframe. Table 6: Power for instrument modules Module type Power (Watts) Mainframe TLA721 Benchtop Controller TLA7XM Expansion Module TLA7AA1 TLA7AA2 TLA7AA3 TLA7AA4 TLA7AB2 TLA7AB4 TLA7NA1 TLA7NA2 TLA7NA3 TLA7NA4 TLA7Q2 TLA7Q4 TLA700 Series Logic Analyzer Installation Manual...
  • Page 73 For power usage in the unshaded region of Figure 29, use either the power cord with the 15 A plug (two parallel prongs and ground) or the power cord with the 20 A plug (two perpendicular prongs and ground). TLA700 Series Logic Analyzer Installation Manual...
  • Page 74 Figure 29, you should consider using the 20A power cord. NOTE. If you are configuring an expansion mainframe, remember to use the power value for the expansion module instead of the benchtop controller. TLA700 Series Logic Analyzer Installation Manual...
  • Page 75 Appendix A: TLA721 Mainframe Power Information TLA700 Series Logic Analyzer Installation Manual...
  • Page 76: Appendix B: User Service Procedures

    Service Offerings Tektronix provides service to cover repair under warranty as well as other services that are designed to meet your specific service needs. Whether providing warranty repair service or any of the other services listed below, Tektronix service technicians are well equipped to service the logic analyzers.
  • Page 77: Preventive Maintenance

    (calibrated). This service must be performed by a qualified service technician using the procedures outlined in the appropriate service manual for the Tektronix Logic Analyzer product. Preventive maintenance mainly consists of periodic cleaning. Periodic cleaning reduces instrument breakdown and increases reliability. Clean the instrument as needed, based on the operating environment.
  • Page 78: Floppy Disk Drive

    Diagnostics from the System menu. You can run more detailed diagnostics by selecting Extended diagnostics. Here you can run all tests, loop on one or more tests, or loop on a test until a failure occurs. TLA700 Series Logic Analyzer Installation Manual...
  • Page 79: Software Problems

    Start menu under the Tektronix Logic Analyzer programs. Repacking for Shipment If a mainframe or module is to be shipped to a Tektronix service center for repair, attach a tag to the mainframe or module showing the owner’s name and address, the serial number, and a description of the problem(s) encountered and/or service required.
  • Page 80 TLAVu software, 47 in a benchtop mainframe, 2 TPI software, 46 in a portable mainframe, 3 Extended diagnostics, 61 External, signal connectors, TLA700 series, 39 External connectors, 40 LA module. See Logic analyzer Logic analyzer chassis ground connections, 6 description, x...
  • Page 81 Index probes, connecting LA probes TLA700 series, 15 merging, 25 reinstalling software, 41 merging guidelines, 25 site considerations, 1 power requirements, 55 TLA700 Series description, ix expansion mainframe, 55 Logical address static logical address, 7 module, 7 three- - way merge procedure, 37...
  • Page 82 Pattern Generator application software, 45 Tektronix, contacting, xii PPI software, 46 Three- - way merge procedure, 37 TLA application software, 45 TLA700 Series, logic analyzer description, ix TLAVu software, 47 TLA7XM Expansion Mainframe TPI software, 46 installing, 2 Removing the hard disk drive, 22...
  • Page 83 Index TLA700 Series Logic Analyzer Installation Manual...
