Mainboard Replacement Process

Preliminary Requirements
Required Tools and Components
Tools
T6 (Torx) driver
•
Anti-static wrist strap (1 MOhm resistance)
•
Soft ESD safe mat
•
Microfiber / lint free cloth
•
Cotton swab
•
Plastic pry tool (spudger)
•
Plastic tweezers
•
Components
Mainboard (Refer to Illustrated Service Parts List)
•
Mainboard Screw (PN) Qty. 2
•
Trigger Screw (PN) Qty. 2
•
Prerequisite Steps
Power Off Device
Ensure device is powered off and disconnected from its power source.
Disconnect the device charger or power cord from mains power.
•
Let the device sit until the Xbox button in the center of the controller is no longer
•
illuminated or by holding the Xbox button and selecting "Turn off controller".
Remove the batteries from the compartment.
•
Remove Top Case
Remove the top case as detailed in the Procedure – Removal (Top Case) for the appropriate
device. (page 14)
Remove Bumper
Remove the bumper as detailed in the Procedure – Removal (Bumper) (page 26)
