Diagram 1a
PowerZone™ Connect two channel amplifier dimensions.
(Shaded area defines ventilation space.)
Diagram 1b
PowerZone™ Connect four channel amplifier dimensions.
(Shaded area defines ventilation space.)
80 mm
3.1 in
80 mm
3.1 in
213 mm
8.4 in
319 mm
12.6 in
Overview
44 mm
1.7 in
25 mm
1.0 in
220 mm
8.7 in
44 mm
1.7 in
25 mm
1.0 in
220 mm
8.7 in
