Blaze PowerZone Connect 1002 Quick Start Manual

Carton Contents
• Amplifier unit • Output connector x 1 or 2
• Rack mount ears (fitted) x 2 • Adhesive rubber feet x 4
• Mains power cable • Document pack
• Input connector x 2 • GPIO socket connector
Installation Notes
• High or low impedance speaker connection options can
be selected independently for each output channel via the
PowerZone™ Control Web App.
• Analogue input sensitivity can be adjusted independently for
each channel via the PowerZone™ Control Web App.
• S/PDIF digital audio I/O routing can be configured via the
PowerZone™ Control Web App.
• GPIO (General Purpose Input/Output) options can be
configured via the PowerZone™ Control Web App.
QUICK START GUIDE
PowerZone™ Connect 1002 • 1502 • 2004/2004D • 3004/3004D
A full user manual including information on installation, mounting
accessories and amplifier operation is available online.
Connection Sockets
• Optional Audinate Dante
over IP (AoIP) networks and installations.
• Ensure that rack or other confined installation does not
restrict the airflow required for safe and reliable operation
of the equipment. It is important to ensure that the 40°C
maximum operating temperature for the equipment is not
exceeded.
Blaze Audio HQ, Pascal A/S, Ellekaer 6, DK-2730 Herlev, Denmark. hello@blaze-audio.com, www.blaze-audio.com
Blaze Audio Americas, Pascal Inc., (888) 500-0109, help@blaze-audio.com
Configurable
Network
GPIO
Control
Dante S/PDIF
®
(optional) Audio I/O
® interface for integration with audio
Audio Inputs
Balanced: Euroblock Mains
Unbalanced: RCA Phono Power Input
Configurable
Speaker Outputs
