6. Attach the Seat (10) to the Seat Frame (9) with
four M6 x 16mm Screws (33) (only two Screws
are shown); start all the Screws, and then
tighten them.
7. Slide the Backrest Frame (8) onto the Seat
Frame (9).
Attach the Backrest Frame (8) with four
M6 x 30mm Screws (41) and four M6 Washers
(35); start all the Screws, and then tighten
them.
6
10
7
8
35
41
9
9
33
9
