Specifications - Lectrosonics HHa-941 Instruction Manual

Specifications

Operating Frequencies:
HHa:
HHa-941:
HHa/E01:
HHa/E02:
HHa/E06:
HHa/E07:
HHa/E07-941:
HHa/X:
NOTE: It's the user's responsibility to select the
approved frequencies for the region where the
transmitter is operating
Compatibility Modes:
RF Power output:
HHa:
HHa-941:
HHa/E01:
HHa/E02:
HHa/E06:
HHa/E07:
HHa/E07-941:
HHa/X:
Pilot tone:
Frequency stability:
Spurious radiation:
Operating temperature range:
Input compressor:
Gain control range:
Modulation indicators:
Frequency response
Low frequency roll-off:
Rio Rancho, NM
Band A1: 470.100 - 537.575
Band B1: 537.600 - 607.950
941.525 - 951.975 MHz
952.875 - 956.225 MHz
956.475 - 959.825 MHz
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band 606: 606.000 - 631.500
Band C1: 614.400 - 691.175
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
Band B1: 537.600 - 614.375
Band C1: 614.400 - 691.175
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
941.525 - 951.975
953.025 - 956.225
956.475 - 959.825
Band A1: 470.100 - 537.575
Band B1: 537.600 - 614.375
Band 606: 606.000 - 631.500
Band C1: 614.400 - 691.175
HHa: Nu Hybrid, IFB, Mode 3
HHa-941, HHa/E07-941: Nu Hybrid, IFB
HHa/E01: Nu Hybrid, IFB, Mode 3
HHa/E02: Digital Hybrid Wireless®, IFB, Mode
3, Mode 6
HHa/E06: Hybrid, IFB, Mode 3
HHa/X: Hybrid, Mode 3, 200 Mode, 100 Mode,
Mode 7, Mode 6, IFB Mode
Selectable 50 or 100 mW
Selectable 50 or 100 mW
Selectable 25 or 50 mW
10 mW
Selectable 50 or 100 mW, EIRP
Selectable 25 or 50 mW
Selectable 50 or 100 mW
Selectable 50 or 100 mW
25 to 32 kHz
± 0.002%
Compliant with ETSI EN 300 422-1
-20° C to +50° C
Dual envelope compressor, >30 dB range
45 dB; semi-log menu-driven control; 1 dB steps
Dual bicolor LEDs indicate modulation
of -20, -10, 0 and +10 dB referenced to full
modulation, LCD bar-graph indicator
40 Hz to 20 kHz (+/- 1dB)
-3 dB @35, 50 and 70 Hz; selectable;
12 dB/octave (varies slightly with selection)
Wideband Hand Held Transmitter
System dynamic range:
SmartNR no limiting
OFF 103.5
NORMAL 107.0
FULL 108.5
Note: The dual envelope "soft" limiter provides exceptionally good handling of
transients using variable attack and release time constants. Once activated, the
limiter compresses 30+ dB of transmitter input range into 4.5 dB of receiver output
range, thus reducing the measured figure for SNR without limiting by 4.5 dB.
Controls:
External:
I nternal control panel:
Battery:
Battery life:
Capsule Interface:
Weight:
Dimensions:
Emission Designator:
HHC capsule
cardioid pickup
pattern
Specifications subject to change without notice.
w/limiting
108.0
111.5
113.0
Programmable mute/talkback button
Power, Side Button Setup, MENU/SEL, BACK
and Up/Down arrow buttons for menu item
2x AA with polarity protection and
battery ejector
At 100mW: 5.5 hours (Duracell Ultra
alkaline) (The HH transmits battery status to
Lectrosonics Digital Hybrid Wireless
®
1.25" opening and 28 thread pitch
Power available: 5V, 25 mA max
Input impedance: 1000 Ohms
12.1 oz. (343.029 grams) with batteries and
HHC capsule
9.5" long x 1.97" diameter at largest point
241.3 long x 50.038 mm diameter at
largest point
A1: 39K7F3E
B1: 57K9F3E
X, 941: 180KF3E
E07-941: 110KF3E
receivers.)
