Page 1: Handheld Transmitter
INSTRUCTION MANUAL Handheld Transmitter Digital Hybrid Wireless Technology ® US Patent 7.225.135 Fill in for your records: Serial Number: Purchase Date: Rio Rancho, NM, USA www.lectrosonics.com... -
Page 2: Table Of Contents
To operate wireless microphone systems at power greater than 50mW, you must qualify as a Part 74 user and be licensed. If you qualify and wish to apply for a license go to: http://www.fcc.gov/Forms/Form601/601.html LECTROSONICS, INC. -
Page 3: General Technical Description
FM systems, the Digital Hybrid has elimi- the flexibility of digital signal processing, however, the nated the analog compandor and its artifacts. transmitter is also able to operate with Lectrosonics 200 Series, Lectrosonics 100 Series, IFB and certain Wide Deviation non-Lectrosonics analog receivers in special compat- ibility modes. - Page 4 It can be thought of as two limiters in series, a fast attack and release The HH handheld transmitter is available from Lectro- limiter followed by a slow attack and release limiter. sonics with the HHC and HHVMC cardioid condenser The limiter recovers quickly from brief transients, with capsules.
-
Page 5: Microphone Capsules
28 threads per inch and three contact rings Microphone Capsules: Lectrosonics offers two types of capsules. The HHC is the standard capsule and the HHVMC is the Variable Mic Capsule which includes adjustments for Bass, Midrange and Treble. -
Page 6: Battery Installation
“standby” mode with the RF output turned off. problem that occurred. IR Sync IR Sync COMPAT Mismatch LECTROSONICS, INC. -
Page 7: Powering Off
Hand Held Transmitter Powering Off Battery Condition Press and hold the Power Button (or the side button An icon on the Main Window indicates the remaining if it is configured for turning the power on and off) for power of the transmitter batteries. This battery gauge several seconds and observe the countdown on the is most accurate with the typical voltage drop across LCD. - Page 8 Gain Compat This setting is very important since it will determine the The HH can be used with earlier Lectrosonics wireless audio signal to noise ratio and dynamic range that the and IFB systems and systems from other manufactur- wireless system will deliver. Gain must be set accord- ers by selecting the correct Compatibility Mode.
-
Page 9: Input Gain Adjustment
Hand Held Transmitter Input Gain Adjustment Phase The phase (polarity) of the audio can be inverted to The two bicolor Modulation LEDs (located at the bot- match other microphone capsules as needed. tom of the control panel) provide a visual indication of the audio signal level entering the transmitter. -
Page 10: Side Button Functions
Power turns the power on and off. <–MUTE–> Button Hold the button in until the count- down sequence from 3 to 1 is Talkback active Mute active Power completed. The power will then be (MUTE blinks) turned off. (additional information on page 7) LECTROSONICS, INC. -
Page 11: Mic Capsule Adjustments
Hand Held Transmitter Mic Capsule Adjustments Resonance tuned HHVMC capsule (EXPERT LEVEL ADJUSTMENT) suspension These adjustments significantly alter the gain and tonal quality of the microphone, and are to be used only in special circumstances. Caution: Always make the final decision about sound quality with the windscreen in place. -
Page 12: Parts And Accessories
HH transmitter. #CCHH - Zippered Pouch Transmitter interface Capsule interface Padded zipper pouch for handheld transmitter HHA Adapter by Ambient Recording #26872 Mic Capsule Wrench Adapts Neumann KK104 and Custom wrench for removing windscreen from mic... -
Page 13: Troubleshooting
Hand Held Transmitter Troubleshooting SYMPTOM POSSIBLE CAUSE HH WILL NOT POWER ON 1) Batteries are inserted backwards. 2) Batteries are dead, or too low to be used. HH MODULATION LEDs OFF 1) Audio Gain set too low. 2) Battery is inserted backwards. Check LCD for power indication. 3) Mic capsule is damaged or malfunctioning. -
Page 14: Specifications
Power, Side Button Setup, MENU/SEL, BACK and Up/Down arrow buttons for menu item (Fine Tuning mode) 1024 frequencies in 25 kHz steps (except block 23 - contact Lectrosonics for details) selection and settings. Channel Step Size: Battery: (2) AA with polarity protection and... -
Page 15: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a mod- est flat rate plus parts and shipping. - Page 16 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
