Summary of Contents for Lectrosonics HHa-941
-
Page 1: Digital Hybrid Wireless
INSTRUCTION MANUAL Handheld Transmitter HHa, HHa-941, HHa/EO1, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Digital Hybrid Wireless ® US Patent 7,225,135 For FCC Part 74 licensed operators Fill in for your records: Serial Number: Rio Rancho, NM, USA Purchase Date: www.lectrosonics.com... - Page 2 , HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Industry Canada Compliance: This device operates on a no-protection no-interference basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio license is required. Please consult Industry Canada’s document CPC-2-1-28, Optional Licensing for Low-Power Radio Apparatus in the TV Bands, for details.
-
Page 3: Table Of Contents
Wideband Hand Held Transmitter Table of Contents Digital Hybrid Wireless ® ............................................................1 General Technical Description ................................4 Digital Hybrid Wireless Technology ..............................4 ® Microphone Capsules: ...................................6 Mechanical Assembly ....................................6 Battery Installation ....................................7 IR Sync ........................................7 Control Panel ......................................7 Setup and Adjustments ..................................7 Powering On ......................................7 Powering Off ......................................8 Standby Mode .......................................8... -
Page 4: General Technical Description
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X General Technical Description Digital Hybrid Wireless Technology Introduction ® The HHa handheld transmitter uses state-of-the-art All wireless links suffer from channel noise to some Digital Hybrid Wireless wireless technology, select- ® degree and all wireless microphone systems seek to able output power and a versatile microphone capsule minimize the impact of that noise on the desired signal. - Page 5 USB Port for Firmware Updates Wideband Tuning Range Firmware updates are enabled by simply downloading a file and utility program from the Lectrosonics web- The transmitter can tune across bands of up to 76 site, connecting the transmitter to a computer via the MHz in either 100 kHz or 25 kHz steps.
-
Page 6: Microphone Capsules
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Mechanical Assembly A mic capsule is threaded onto the body of the transmitter in the direction shown. Do not overtighten it. The lower housing opens by rotating it in the direction shown. After the... -
Page 7: Battery Installation
Wideband Hand Held Transmitter Battery Installation Control Panel To insert batteries, close the eject lever and insert the Six membrane switches on the control panel are used upper contacts first (closest to the mic capsule). Polar- to set up the transmitter by navigating the menus on ity is marked on the label in the bottom of the battery the LCD and selecting the desired values. -
Page 8: Powering Off
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Powering Off The unit can also be turned off from any menu or Press and hold the Power Button (or the side button screen on the LCD by holding the power button in for if it is configured for turning the power on and off) for the duration of the countdown. - Page 9 Gain Compat This setting is very important since it will determine the The HHa can be used with earlier Lectrosonics wire- audio signal to noise ratio and dynamic range that the less and IFB systems and systems from other manu- wireless system will deliver.
-
Page 10: Input Gain Adjustment
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Input Gain Adjustment TxPower Output power can be set to 100 mW (50 mW/E01) The two bicolor Modulation LEDs (located at the bot- to extend operating range (which can also suppress tom of the control panel) provide a visual indication of noise and dropouts to some extent) or set to 50 mW the audio signal level entering the transmitter. -
Page 11: Programmable Switch Functions
Wideband Hand Held Transmitter Programmable Switch Cough is a momentary mute switch. ProgSw Audio is muted while the button is Functions held in. Cough NOTE: The Power and Cough functions were added starting with serial number 1001. A special button (the Side Button) on the outside of the housing can be configured to provide several differ- Mute is a “push on/push”... -
Page 12: Mic Capsule Adjustments
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Mic Capsule Adjustments Resonance tuned HHVMC capsule suspension (EXPERT LEVEL ADJUSTMENT) These adjustments significantly alter the gain and tonal quality of the microphone, and are to be used only in special circumstances. -
Page 13: Parts And Accessories
Wideband Hand Held Transmitter Supplied Parts and Optional Parts and Accessories Accessories CCHH - Zippered Pouch HHXTND Padded zipper pouch for handheld transmitter Extender for use with microphone flags commonly used in ENG for network or station ID to keep the flag from covering the side switch and LCD 13585 Mic Clip HH2SEN Adapter... -
Page 14: Firmware Update
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Firmware Update Step 2: Next, test the Updater by opening the icon: If the Updating the firmware is a simple matter of download- driver opens automatically, proceed to Step 3. ing a utility program and file from the website and run-... - Page 15 Spring-loaded balls USB Port engage detents in housing Step 7: In Lectrosonics USB Firmware Updater, choose the Step 4: detected device, browse to local Firmware File and click Start. Open Lectrosonics USB Firmware Updater. NOTE: It may take up to a minute or so for the Updater to recognize the transmitter.
-
Page 16: Troubleshooting
, HHa-941, HHa/E01, HHa/E02, HHa/E06, HHa/E07, HHa/E07-941, HHa/X Troubleshooting SYMPTOM POSSIBLE CAUSE TRANSMITTER WILL NOT POWER ON 1) Batteries are inserted backwards. 2) Batteries are dead, or too low to be used. HHa MODULATION LEDs OFF 1) Audio Gain set too low. -
Page 17: Specifications
57K9F3E Compatibility Modes: HHa: Nu Hybrid, IFB, Mode 3 X, 941: 180KF3E HHa-941, HHa/E07-941: Nu Hybrid, IFB E07-941: 110KF3E HHa/E01: Nu Hybrid, IFB, Mode 3 HHa/E02: Digital Hybrid Wireless®, IFB, Mode 3, Mode 6 HHa/E06: Hybrid, IFB, Mode 3... -
Page 18: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS’ Service Department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out-of-warranty repairs are charged at a mod- est flat rate plus parts and shipping. - Page 19 Wideband Hand Held Transmitter Declaration of Conformity Notified Body Statement of Opinion Rio Rancho, NM...
- Page 20 This warranty does not apply to used or demonstrator equipment. Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item.
