HOMCOM 823-039V70CW Assembly Instruction Manual page 9

Control Panel
This section explains how to use this appliance.
FAN
Indicators
Low fan speed
Automatic swing
Dehumidify
Automatic
Control Panel Operation
● Automatic, cool,fan and dehumidify.
1. Turn on the unit
a) Plug in - the unit beeps once.
b) Press to turn the unit on.
The LED displays the room temperature.
Press the button again to turn the unit off.
2. Select operating mode
Press - each time the mode will circle as below. When the mode indicator
flashes and no button is pressed for several seconds, the operation mode will
be selected.
3. Adjust Temperature
When in cool mode, the temperature can be set between 15- 31 °C.
Press or once to increase or decrease the temperature by 1 °C.
The unit LED shows the target temperature for five seconds, then displays the
room temperature.
Middle fan speed
Cool
Timer on
9
High fan speed
Fan
Timer off
