MICRO-EPSILON scanCONTROL 3000 Assembly Instructions Manual page 3

scanCONTROL
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
5. Connections, LED Displays
1 2
Multifunction Port
Designation Sensor connector
Pin
+Ub
GND
+Laser on/off
-Laser on/off
RS422
/RS422
GND RS422
In1
In2
In3
In4
GND-In
Screen
scanCONTROL 3000 / 3050
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P ≤ 10mW, P ≤ 10mW; E≤ 6mW/cm²;
0 P
λ = 405nm; F = 0...25kHz, t = 7µs...∞
1 Multifunction Port (power supply, I/O)
2 Ethernet port
Cable color
PCR3000-x
9
2
3
1
12 Red-blue
11 Gray-pink
10
4
6
8
5
7
Housing
LASER
APERTURE
Red
(rated value 24 V); max. 5 W
Blue
White
Available with SI option
Brown
Purple Ground connection RS422
Green
Yellow
Gray
Pink
Black Ground connection In
Black Not electrically connected to GND
Fig. 3 Sensor with
laser labels
Notes
+ 11 V - 30 V DC
0 V
RS422
input or output
Switching input In1
Switching input In2
Switching input In3
Switching input In4
