AirCom HT Series Instruction Manual

Hide thumbs Also See for HT Series:
Table of Contents

Advertisement

Quick Links

Download this manual
CONVENTIONAL SPRAY GUNS
HT series
Instruction
manual
153
80
39
47
mod. HT, HT-X, HT-XC
EN
aircom.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT Series and is the answer not in the manual?

Questions and answers

Related Manuals for AirCom HT Series

Summary of Contents for AirCom HT Series

  • Page 1 CONVENTIONAL SPRAY GUNS HT series Instruction manual mod. HT, HT-X, HT-XC aircom.it...
  • Page 2 Presence of optional washing circuit mod. HT-X Stainless steel internal passages Presence of optional washing circuit mod. HT-XC Stainless steel inner passages and spray head Presence of optional washing circuit AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0...
  • Page 3 HT series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...

  • Page 4: Maintenance And Cleaning

    Do not supplied by AIRCOM® is not approved or immerse the gun in liquid cleaners that authorized. AIRCOM® is not liable for any may cause corrosion of the product.

  • Page 5: Installation

    HT series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,79 kg Gun size:...
  • Page 6 HT series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS OPERATION Pipe Ø ext. X Ø int. = 8 X 6 Plunger opening ≥...

  • Page 7: Adjustment Sequence

    HT series ADJUSTMENT SEQUENCE 1.Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. 2.Connect the atomization air, control air and product piping to the junctions shown on the previous page.

  • Page 8: Technical Data

    HT series TECHNICAL DATA HEAD 1007-30-KI HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1007-30-KI ø 0,8 1,65 1007-30-KI ø 1,0 2,25 1007-30-KI ø 1,2 2,65 1007-30-KI ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm².
  • Page 9 HT series TECHNICAL DATA HEAD 1007-30-WI HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1007-30-WI ø 0,8 1,65 1007-30-WI ø 1,0 1007-30-WI ø 1,2 2,35 1007-30-WI ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm².

  • Page 10: Troubleshooting

    HT series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Valve part. [1007-43] worn out Replace valve part. [1007-43] worn out The head part. [1007-30], the nozzle part. [1007-2] and the needle part. [1121-1] are worn out.
  • Page 11 CONVENTIONAL SPRAY GUNS HT series mod. HT, HT-X, HT-XC Spare parts and components aircom.it...

  • Page 12: Spare Parts

    HT series SPARE PARTS mod. HT DETAILS LIST 1007-2 [x1]Nozzle 1007-3 [x1]Ferrule 1007-7 [x2]Adjusting screw 1090-13 [x1]Cap 1007-30 [x1]Head 1121-1 [x1]Complete needle 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1090-11 [x1]Mounted plunger [x1]Seeger [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-G25 [x1]Mounted hand wheel...
  • Page 13 HT series SPARE PARTS mod. HT-X DETAILS LIST 1007-2 [x1]Nozzle 1007-3 [x1]Ferrule 1007-7 [x2]Adjusting screw 1090-13 [x1]Cap 1007-30 [x1]Head 1121-1 [x1]Complete needle 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1090-11 [x1]Mounted plunger [x1]Seeger [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-G25 [x1]Mounted hand wheel...
  • Page 14 HT series SPARE PARTS mod. HT-XC DETAILS LIST 1007-2 [x1]Nozzle 1007-3 [x1]Ferrule 1007-7 [x2]Adjusting screw 1090-13 [x1]Cap 1007-30-X [x1]Stainless steel head 1121-1 [x1]Complete needle 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1090-11 [x1]Mounted plunger [x1]Seeger [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-G25 [x1]Mounted hand wheel...
  • Page 15 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X 1007-30-KI NOZZLE NEEDLE 1007-30-KI-0.8 1007-2-0.8 1056-31-0.8 1056-31-1.0 1007-30-KI-1.0 1007-2-1.0 1007-30-KI-1.2 1007-2-1.2 1056-31-1.2 1056-31-1.5 1007-30-KI-1.5 1007-2-1.5 1056-31-1.8 1007-30-KI-1.8 1007-2-1.8 1007-30-KI-2.0 1056-31-2.0 1007-2-2.0 1056-31-2.2 1007-30-KI-2.2 1007-2-2.2 1007-30-KI-2.5 1056-31-2.5 1007-2-2.5 1007-30-KI-3.0 1056-31-3.0 1007-2-3.0 1007-30-ZI NOZZLE NEEDLE 1007-30-ZI-0.8...
  • Page 16 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X 1007-30-NI NOZZLE NEEDLE 1007-30-NI-0.8 1007-2-0.8 1056-31-0.8 1056-31-1.0 1007-2-1.0 1007-30-NI-1.0 1007-30-NI-1.2 1007-2-1.2 1056-31-1.2 1007-30-NI-1.5 1056-31-1.5 1007-2-1.5 1007-30-NI-1.8 1056-31-1.8 1007-2-1.8 1007-30-NI-2.0 1056-31-2.0 1007-2-2.0 1056-31-2.2 1007-30-NI-2.2 1007-2-2.2 1056-31-2.5 1007-30-NI-2.5 1007-2-2.5 1007-30-NI-3.0 1056-31-3.0 1007-2-3.0 1007-30-TI NOZZLE NEEDLE 1007-30-TI-0.8...
  • Page 17 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X 1007-30-WI NOZZLE NEEDLE 1007-30-WI-0.8 1007-2-0.8 1056-31-0.8 1056-31-1.0 1007-30-WI-1.0 1007-2-1.0 1007-30-WI-1.2 1007-2-1.2 1056-31-1.2 1056-31-1.5 1007-30-WI-1.5 1007-2-1.5 1007-30-WI-1.8 1056-31-1.8 1007-2-1.8 1007-30-WI-2.0 1056-31-2.0 1007-2-2.0 1007-30-WI-2.2 1056-31-2.2 1007-2-2.2 1007-30-WI-2.5 1056-31-2.5 1007-2-2.5 1007-30-WI-3.0 1056-31-3.0 1007-2-3.0 1007-30-LE NOZZLE NEEDLE 1007-30-LE-0.8...
  • Page 18 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X 1007-30-SI NOZZLE NEEDLE 1007-30-SI-0.8 1007-2-0.8 1056-31-0.8 1056-31-1.0 1007-2-1.0 1007-30-SI-1.0 1007-30-SI-1.2 1007-2-1.2 1056-31-1.2 1007-30-SI-1.5 1056-31-1.5 1007-2-1.5 18 - Spare parts and components aircom.it...
  • Page 19 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT-XC 1007-30-KX NOZZLE NEEDLE 1007-30-KX-0.8 1007-2-0.8 1056-31-0.8 1056-31-1.0 1007-2-1.0 1007-30-KX-1.0 1007-30-KX-1.2 1007-2-1.2 1056-31-1.2 1007-30-KX-1.5 1056-31-1.5 1007-2-1.5 1056-31-1.8 1007-30-KX-1.8 1007-2-1.8 1056-31-2.0 1007-30-KX-2.0 1007-2-2.0 1056-31-2.2 1007-30-KX-2.2 1007-2-2.2 1056-31-2.5 1007-30-KX-2.5 1007-2-2.5 1007-30-KX-3.0 1056-31-3.0 1007-2-3.0 1007-30-ZX NOZZLE NEEDLE 1007-30-ZX-0.8...

  • Page 20: Certified Quality

    Einheisblatt 24 366) and therefore also additional guarantee of authenticity according transfer efficiency and Italianity because it is present parameters. exclusively in original AIRCOM® guns. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it Online support 20 - Instruction Manual aircom.it...
  • Page 21 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
  • Page 22 DISCOVER ALL PRODUCTS Follow us aircom.it...

This manual is also suitable for:

HtHt-xHt-xc
