Error codes

TROUBLE:
When a fault occurs, the LED of the joystick will start to flash. A long
delay is followed by a number of flashes with a short delay. Count the
number of flases and look up the according error message in the table
below.
We have two categories:
• Warnings: LED will flash in orange. A warning can be resolved quite easily
(see table below).
• Errors: LED will flash in red. An error might indicate a more serious issue
and/or the device will have to come back to mo-vis.
FLASH COUNT
1
40
LED
Orange
REASON
There is an issue
with a safety
switch con-
nected to the
device. This can
only occur when
Switch type is
set to Safety
switch.
Multi Joystick Installation Manual
REQUIRED
ACTION
You have pro-
grammed a
safety switch,
but the system
cannot detect
one. Check if
you have con-
nected a safety
switch and if you
