NOTE:
using the Q2M half clamp.
5 Slide the unit over a Q2M rod, or any other 6 mm rod, to position the
Multi Joystick on the wheelchair.
A Q2M Rod D6 50 mm is included in your package, but you can use any
other Q2M Rod (e.g. a C- or S-Rod from the Multi Swing).
6 Place and secure the interface unit and all cabling on the wheelchair.
WARNING:
downwards. This is to prevent water from entering the Interface
unit.
7 Place a power on/off (pwr) and/or mode (in) switch, secure their cabling
and insert their connections. You can use the connections on the
Interface unit.
CAUTION:
cover. If the connections are not used, always put or keep the
protective covers in.
CAUTION:
accessories, including switches, must also comply with the MDR
2017/745 regulations (e.g. the mo-vis Twister, tested according to
EN12184 standards).
18
It is not advised, but you may mount the joystick without
Place the Interface unit with the connectors facing
Before inserting a connector, remove the protective
This is Class I Medical Device (MDR 2017/745). All
