CENTRIFUGAL PUMPS with INTEGRAL TRAP
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
North America: 800-752-0183, FAX 800-582-2217
International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245
Oxnard, CA • Union City, TN • Delavan, WI • Mississauga, Ont.
Printed in U.S.A. © 1998, Sta-Rite Industries, Inc.
MAX-E-GLAS II
O W
N E R '
INSTALLATION, OPERATION & PARTS
P4E and P4EA Series MODELS
H.P.
3/4
P4E6D-150L
1
P4E6E-151L
1-1/2
P4E6F-152L
1-3/4
2
P4E6G-153L
2-1/2
3
P4E6H-154L
™
S
M
A
N U A
P4EA6E-150L
P4EA6F-151L
P4EAA6F-177L
P4EA6G-152L
P4EAA6G-153L
L
P4E62D-150L
P4E62E-151L
P4E62F-152L
P4E62G-153L
P4E62H-154L
This manual should be furnished to
the end user of this pump; its use will
reduce service calls and chance of
injury and will lengthen pump life.
S271
(Rev. 1/8/98)
Advertisement
Table of Contents
Related Manuals for STA-RITE MAX-E-GLAS II P4E6D-150L
Summary of Contents for STA-RITE MAX-E-GLAS II P4E6D-150L
- Page 1 293 Wright Street, Delavan, WI 53115 North America: 800-752-0183, FAX 800-582-2217 International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245 Oxnard, CA • Union City, TN • Delavan, WI • Mississauga, Ont. S271 (Rev. 1/8/98) Printed in U.S.A. © 1998, Sta-Rite Industries, Inc.
-
Page 2: Table Of Contents
To avoid unneeded service calls, prevent possible injuries, and get the most out of your pump, READ THIS MANUAL CAREFULLY! The Sta-Rite ‘P4E’ and ‘P4EA’ Series II Self-priming Centrifugal pumps: • Are designed for use with swimming pools or as centrifugal pumps. -
Page 3: Safety Instructions
• Check all clamps, bolts, lids, and system accessories before testing. • Release all air in system before testing. • Tighten Sta-Rite trap lids to 30 ft. lbs. (4.1 kg-m) torque for testing. • Water pressure for test must be less than 25 PSI (7.5 kg/cm2). -
Page 4: Installation
Strainer Basket Cover Discharge Port Clamp to Filter or Pool Knob Bonding Suction Port From Pool or Vacuum Filters Pump may be bolted 1231 0894 to level foundation FIGURE 1 or mounting brackets INSTALLATION Only qualified, licensed personnel should install pump and wiring. Pump mount must: Be solid - Level - Rigid - Vibration free. - Page 5 Piping: Use at least 2" (51mm) IPS PVC pipe. Increase size if a long run is needed. To avoid strains on the pump, support both suction and discharge pipes inde- pendently. Place these supports near the pump. To avoid a strain left by a gap at the last connection, start all piping at the pump and run pipe away from the pump.
-
Page 6: Electrical
ELECTRICAL Ground motor before connecting to electrical power supply. Failure to ground motor can cause severe or fatal electrical shock hazard. Do not ground to a gas supply line. To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. -
Page 7: Operation
OPERA TION NOTICE: NEVER run pump dry. Running pump dry may damage seals, caus- ing leakage and flooding. Fill pump with water before starting motor. Before removing trap cover: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. -
Page 8: Storage/Winterizing
Draining Pump 1. Pump down water level below all inlets to the pool. To avoid dangerous or fatal electrical shock hazard, turn OFF power to motor before draining pump. 2. Remove trap cover and use low pressure air to blow accumulated water from the piping system. -
Page 9: Pump Service
PUMP SERVICE Pump should only be serviced by qualified personnel. Be sure to prime pump (Pg. 7) before starting. Before removing trap cover: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. RELEASE ALL PRESSURE from pump and piping system. 4. - Page 10 Pump Reassembly/Installing New Seal 1. Ceramic seat must be clean and free of dirt, grease, dust, etc. Wet outer edge with small amount of liquid detergent; press ceramic seat into seal plate cavity firmly and squarely with finger pressure (Fig. 5). 2.
- Page 11 Installing Heat Sink Insert: If the heat sink insert moves or shifts during seal removal, remove and replace with a new insert to prevent leakage. Removal: 1. Remove two screws holding heat sink insert to seal plate. 2. Place seal plate face down on bench and use a short length of 1/2” (13 mm) pipe to push insert out of seal.
- Page 12 P4E, P4EA and P4E62 SERIES MAX-E-GLAS II POOL PUMP 3/4 and 3 HP Models 1860 0795...
-
Page 13: Repair Parts List
P4E, P4EA and P4E62 SERIES REPAIR PARTS LIST MAX-E-GLAS II POOL PUMP Part Part Description Qty. 3/4 and 3 HP Models Motor Chart at Right #10-32x1/2” Screw U30-692SS Bonding Lug U17-568 Water Slinger C69-2 Seal Plate C203-187P O-Ring U9-376 O-Ring U9-228A Insert C3-186... -
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE Read and understand safety and operating instructions in this manual before doing any work on pump! Only qualified personnel should electrically test pump motor! FAILURE TO PUMP; REDUCED CAPACITY OR DISCHARGE PRESSURE Suction leaks/lost prime: 1. Pump must be primed; make sure that pump volute and trap is full of water. -
Page 15: Warranty
Retain Warranty Certificate (upper portion) in a safe and convenient location for your records. DETACH HERE: Fill out bottom portion completely and mail within 10 days of purchase/installation to: Sta-Rite, Attn: Warranty Dept., 293 Wright St., Delavan, WI 53115 Warranty Registration Card...
