CENTRIFUGAL PUMPS
TM
WITH INTEGRAL TRAP
O
W
N
E
R '
INSTALLATION, OPERATION & PARTS
P2R AND P2RA Series MODELS
P2R Series
P2RA5C-119L
P2RA5D-120L
P2RA5E-124L
P2RA5F-125L
–
P2RA5G-126L
S
M
A
N
U
P2RA Series
P2RAXE-124L
P2RA6F-125L
P2RAXF-125ULS
P2RA6G-126L
A
L
P2RAXF-125LS
P2RAXG-126LS
This manual should be furnished to
the end user of this pump; its use
will reduce service calls and chance
of injury and will lengthen pump life.
S53 (Rev. 11/5/97)
Advertisement
Table of Contents
Related Manuals for STA-RITE P2R Series
Summary of Contents for STA-RITE P2R Series
- Page 1 293 Wright Street, Delavan, WI 53115 North America: 800-752-0183, FAX 800-582-2217 International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245 Oxnard, CA • Union City, TN • Delavan, WI • Mississauga, Ont. S53 (Rev. 11/5/97) Printed in U.S.A. © 1997, Sta-Rite Industries, Inc.
-
Page 2: Table Of Contents
To avoid unneeded service calls, prevent possible injuries, and get the most out of your pump, READ THIS MANUAL CAREFULLY! The Sta-Rite ‘P2R’ and ‘P2RA’ Series Self-priming Centrifugal pump: • Is designed for use with swimming pools or as a centrifugal pump. -
Page 3: Safety Instructions
Check all clamps, bolts, lids, and system accessories before testing. Release all air in system before testing. Tighten Sta-Rite trap lids to 30 ft. lbs. (4.1 kg-m) torque for testing. Water pressure for test must be less than 25 PSI (7.5 kg/cm Water Temperature for test must be less than 100 F. -
Page 4: Installation
FIGURE 1 INSTALLATION Only qualified, licensed personnel should install pump and wiring. Pump mount must: Be solid - Level - Rigid - Vibration free. (To reduce vibration and pipe stress, bolt pump to mount.) Allow pump suction inlet height to be as close to water level as possible. Allow use of short, direct suction pipe (To reduce friction losses). - Page 5 12 (3) 12.0 230/60/1 14 (2) 14 (2) 12 (3) *Time delay fuses are recommended instead of standard fuses in any motor circuit. P2R Series Motor Branch Fuse Max Load Voltage/ Dist. in Ft. (m) (Serv. to Motor) H.P. Rating Amps*...
-
Page 6: Electrical
ELECTRICAL Ground motor before connecting to electrical power supply. Failure to ground motor can cause severe or fatal electrical shock hazard. Do not ground to a gas supply line. To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. -
Page 7: Operation
OPERA TION NEVER run pump dry! Running pump dry may damage seals, causing leakage and flooding! Fill pump with water before starting motor. Before removing trap cover: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. - Page 8 2. Remove trap cover and use low pressure air to blow accumulated water from the piping system. Use a Sta-Rite U79-11 Lid Wrench to remove trap covers that have been overtightened or have taken a set and cannot be removed by hand.
-
Page 9: Pump Service
PUMP SERVICE Pump should only be serviced by qualified personnel. Be sure to prime pump (Page 7) before starting. Before removing trap cover: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. RELEASE ALL PRESSURE from pump and piping system. 4. - Page 10 Pump Reassembly/Installing New Seal: 1. Ceramic seat must be clean and free of dirt, grease, dust, etc. Wet outer edge of O-Ring with small amount of liquid detergent; press ceramic seat into seal plate cavity firmly and squarely with finger pressure (Figure 5).
-
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE Read and understand safety and operating instructions in this manual before doing any work on pump! Only qualified personnel should electrically test pump motor! FAILURE TO PUMP; REDUCED CAPACITY OR DISCHARGE PRESSURE Suction leaks/lost prime: 1. Pump must be primed; make sure that pump volute and trap are full of water. -
Page 12: Repair Parts List
C63-12 CAUTION. . .” P2R5F-126L* 1-1/2 A100FHL C105-137PDBA • Model Plate (P2R Series) 32155-4067 • Model Plate (P2RA Series) U33-121 P2R5 and P2RA5 models include 5” trap, Pkg. 115. P2RX and P2RAX models do not include trap. * Model P2RA5C-119L uses Part No. C1-217P; P2R5C-120L For trap parts, see Page 14. - Page 13 REPAIR PARTS LIST P2R and P2RA SERIES DURA-GLAS POOL PUMP ® 1-1/2 and 2 H.P. Models Part Part Description Qty. Motor Chart at Right Screw #10-32 x 1/2” U30-856ZP 1831 0695 Bonding Lug U17-568 Water Slinger C69-2 Seal Plate C203-137P1 O-Ring U9-228A Insert...
- Page 14 5” TRAP/ADAPTER ASSEMBLY REPAIR PARTS LIST - 5” and 6” TRAPS* PKG. 115 Part No. Part Pkg. 115 Pkg. 161 Description 5” Trap 6” Trap Trap Cover C-139P1 16920-0011 O-Ring - Cover U9-229 16920-0012 Strainer Basket C108-33P 16920-0017 Trap Body C153-53P1 16924-0027 Gasket...
-
Page 15: Warranty
Retain Warranty Certificate (upper portion) in a safe and convenient location for your records. DETACH HERE: Fill out bottom portion completely and mail within 10 days of purchase/installation to: Sta-Rite, Attn: Warranty Dept., 293 Wright St., Delavan, WI 53115 Warranty Registration Card...
