Rocstor DisplayPort Y10A296-B1 User Manual

DisplayPort® 1.4 to HDMI Active Adapter
4K/60Hz – Black
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This Premium Rocstor DisplayPort® 1.4 to HDMI 2.0 Active Adapter - 4K/60Hz allows
you to transmit signals from your host PC to an HDMI monitor. This adapter enables to
output HDMI video with max 4k/60Hz.
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Operation
1- Connect DisplayPort of this product to a DisplayPort display
2- Connect HDMI port of this product to an HDMI monitor
User Manual
Y10A296-B1
®
Features
Upstream:
DisplayPort Male
(Connect to host computer)
• Supports DP1.2
Downstream:
HDMI
• Support HDMI resolution up to 4kx2k@60HZ
• 18Gbps HDMI bandwidth
• Supports 8/10/12 bit color depth output
• Support output pixel format RGB/YCbCr4:4:4/YCb
Cr4:2:2/YCbCr4:2:0
• Support HDCP 2.2&HDCP1.4
• Support HDR
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Resolution
HDMI Resolutions
HDMI Bandwidth
Size (LxWxH)
Weight
Accessory
User Manual
Power
Input Voltage
Power Consumption
DisplayPort Male x1
HDMI Female x1
3 Year
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
FCC, CE
Up to 4KX2K@60HZ
18Gbps
8"x0.88"x0.45" - 205x22.5x11.5 mm
0.9oz - 26gr
English Version
3.3V
0.65W
