Rocstor Y10A239-B1 User Manual

Mini DisplayPort to HDMI Adapter
M/F- 4K 60Hz- Black
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This Premium Rocstor Mini DisplayPort 1.2 to HDMI (4kx2k@60HZ) Adapter. It allows
you to transmit signals from a Mini DisplayPort source ( Macbook Pro， Macbook Air，
etc) to an ultra high de nition HDMI display (TV sets, projectors, etc). With this
product, you can watch videos or slideshows together on the big screen.
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• Main unit x1
• User Manual x1
Operation
1- Connect Mini DisplayPort of this product to Macbook Pro or Macbook Air or
other Mini DisplayPort source devices.
2- Connect HDMI port of this product to an HDMI monitor.
System Requirement
Host computer with an available Mini DisplayPort
Operating systems
- Windows 7 / 8 / 10 / 11
- Android OS
- Chrome OS
- Linux OS
- Mac OS v10.5 or above
User Manual
Y10A239-B1
®
Features
Upstream:
Mini DisplayPort - Male
(Connect to host computer)
• Compliant with DP1.2 speci cation,
and downward compatible with lower versions
Downstream:
HDMI - Female
• Support HDMI resolution up to 4kx2k@60HZ
• 18Gbps HDMI bandwidth
• Support content protection of HDCP
• EDID pass-through from PC source to display
• Support 3D format and compliant with lower versions
• Support power automatic management
Note:
When the resolution of the Mini DisplayPort source doesn't support
4kx2k@60Hz while the max resolution of the HDMI display is
4kx2k@60Hz, the screen of the display may splash or go dark.
Speci cation
Input / Output Connector
Input
Output
Warranty
Limited Warranty
Resolution
HDMI Resolutions
HDMI Bandwidth
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Size (LxHxW)
Weight
0 A ccessory
User Manual
Mini DisplayPort Male x1
HDMI Female （ HDMI V2.0） x1
2-Year
Up to 4KX2K@60HZ
18Gbps
0°C to + 45°C - (32°F to + 113°F)
10% to 90 % RH (no condensation)
-10°C to + 70°C - (14°F to + 158°F)
10% to 90 % RH (no condensation)
FCC, CE
6.13"x0.47"x0.87" - 155x 12 x 22 mm
1 oz - 28gr
