VIP-100 II Series H.264 Encoder Decoder User Manual
Introduction
The VIP100 II series incorportates the advanced H.264 codec as the
compression type, which makes it occupy lower bandwidth and transmit
over the LAN more smoothly. It supports 120m over single cat5e/6 cable at
point to point, as well as point to many and many to many over Ethernet
switch. The over IP solution is widely used in various locations, like meeting
room, class room, metro, airport, home, mall advertisement...etc.
1. Features
1). Using H.264 compression encoding, support resolution up to
1080p@60hz
2). Transmit up to 120m over single Cat5e/6 cable, with 1x looping HDMI
output
3). With IR Remote to choose the source, with LED to show the Group ID
4). Comply with TCP/IP protocol, streaming bit rate is up to 15Mbps
5). Support LPCM audio format
6). Smart IP Address Setting: Dynamic Host Configuration Protocol (DHCP)
7). Wide-band IR pass through to control the source (38khz to 56khz)
8). By pass 2 way UART/RS232 (Up to 115200), use remote controller to
select 8 group Baud rate
9). Support one to one, one to many, many to one, many to many modes,
with large cascade
10). Dual power input: 802.3af compliant POE & DC 5V (No need power
supply when connecting with POE Switch)
11). HDCP Compliant
12). Support PC tool control
13). DC 5V 1A power supply
2
