OVERRIDE MODE
To ENTER
START
Press once
HIGH
3 hours
4 second hold
To EXIT
Back to Daily Schedule
Press & Hold
WIRING INSTRUCTIONS
Hazardous Voltage: Always turn off power at the circuit breaker before wiring. The pump can be wired to 230 VAC
(factory default) or 115 VAC supply. Move the jumper to the corresponding input voltage as shown.
230 VAC
(Default)
115 VAC
MEDIUM
LOW
STOP
3 hours
3 hours
No time limit
Press for
Light flashes slowly
NEXT SPEED
in OVERRIDE MODE
Solid
Jumper in
230V position
L1
L2
Ground
Jumper in
115V position
L1
N
Ground
XE Pump Series
®
TriStar
XE | MaxFlo
QUICK START GUIDE
For detailed information
about XE Series Pumps,
scan this QR code
SIMPLE BUTTON PROGRAMMING
Energy Efficient
Variable Pump Speed
QRG3200VSM REV A
®
®
XE | Super Pump
XE
®
This illustration is showing TriStar
XE.
Programmable
