LAMAX Street2 - Bluetooth Speaker Manual

Overview

1	Micro USB
2	AUX
3	USB
4	Micro SD Card
5	Power	Power on / off (hold) Change source (press)
6	PLAY	Play / pause (press) Answer / end call (press), reject (hold), redial last number dialled (double tap) Unpair (hold)
7	VOL+	Next track (press), increase volume (hold), TWS (double tap)
8	VOL–	Previous track (press), decrease volume (hold)
9	LED	Lights red whilst charging, lights green when fully charged
10	LED2	Flashes while playing or waiting for pairing, lights up in stand-by.

Main Features

Total power of 15 W
IP55 waterproofing
Built-in 1800 mAh rechargeable lithium battery that can last 23 hours on a single charge
TWS for pairing with a second identical speaker

Turning On / Off

Hold the POWER button to turn on the speaker. The LED lights up and a beep sounds. Hold down the same button to turn off the speaker.

Pairing

Press and hold the POWER button to turn on the speaker. The LED flashes blue and the speaker is ready to pair.
A ctivate Bluetooth connectivity on your phone or other device. Select „LAMAX Street2" from the list of available devices. If a pairing code is required, enter „0000" and confirm. When pairing is successful, the speaker emits a beep and the LED lights up blue.
Playback can be controlled either with a paired device or directly on the speaker itself. While playing, the LED flashes blue.

TWS

To pair two speakers together, switch on both speakers and make sure they are not paired with any multimedia device. On one of them, which will act as the main one, press VOL+ twice in succession, a beep will sound. When pairing is successful, a second beep sounds and the main speaker acts as the left channel.

Audio Input

Connect to the AUX jack via the supplied audio cable to play music from any device. It is not possible to control songs directly on the speaker itself when playing back via the audio input.

Handsfree

The handsfree function is activated when you pair your phone via Bluetooth. Press PLAY to answer / end the call, hold down PLAY to reject the incoming call, and tap PLAY twice to redial the last number dialed.

FM Radio

Make sure the audio cable is connected, it serves as an antenna. Use the POWER button to switch to the FM radio. Hold down the PLAY button to automatically scan for radio stations. When scanning is complete, press VOL+ and VOL– to switch between stations.

Charging

The speaker can be charged using the included USB cable plugged into a suitable USB device – adapter, PC, power bank. Do not charge the speaker with a higher input voltage than 5V, the speaker may be damaged. When the battery is running low, a beep sounds. When charging the light is red, and turns green when fully charged.

Parameters

Speaker Parameters	2 × 7,5 W, Φ 50 mm, 150 Hz – 20 KHz
Battery	Li-Ion 1800 mAh
Playback Time	up to 23 hours
Charging Time	3 hours
Playback Options	Bluetooth, 3.5 mm audio input, microSD card
Wireless Technology	Bluetooth 5.0
Waterproofing	IP55 – protection against water spray
Dimensions	195 × 70 × 50 mm
Weight	380 g
