LAMAX PartyBoomBox500 Manual

Rear Panel and Controls

1. Volume level control
2. Bass level control
3. treble level control
4. Microphone volume level control
5. Microphone echo effect level control
6. 12V battery input
7. AUX iNpUt
8. Microphone input
9. Charging adapter input
10. LED On/Off switch
11. power switch

Charging and LED Indicators

Fully charge the speaker battery before first use, using the adapter included.

Indicators:

• LED glows red – the speaker battery is charging
• LED glows green – the speaker battery is fully charged

Note: Low battery status results in a gradual reduction in performance and possible audio outages. in this case, immediately connect the power to the speaker or turn it off.

Powering On / Off

to turn the speaker on/off, press the POWER button. the display lights up and a beep sounds.

Pairing via Bluetooth

1. Turn on the speaker and make sure Bluetooth mode is selected on the display. if it is not selected, press the MODE button below the rear panel display to select it. the speaker is now ready for pairing.
2. Activate the Bluetooth connection on your smartphone or other device. Select "LAMAX partyBoomBox500" from the list of available devices. When pairing is successful, the speaker beeps.
3. Playback can be controlled either by a paired device, directly on the speaker or via remote control.

Note: the Bluetooth connection works best within 10 metres in an open area.

TWS

To pair two speakers, turn on both speakers and make sure they are not paired with the multimedia device. Set both devices to the Bluetooth mode by pressing the MODE button, the LCD display shows "no B". Hold down the PLAY/PAUSE button for 5s on one of them, which will be the main one. A beep sounds and the main speaker acts as the right channel. The other speaker also beeps and acts as the left channel.

To unpair the speakers, hold the same MODE button on the main speaker, or turn one off.

Player Controls

Using an External AUX Source

1. Select "AUX" using the MODE button on the rear panel of the unit.
2. Connect your audio device to the external AUX iN input on the rear panel. You can then control playback on the external audio device or on the speaker itself.

Using the Microphone

1. Connect the microphone that comes included to the MIC IN input on the rear panel of the unit and turn the microphone switch to the ON position.
2. Turn the MIC VOL control on the rear panel to increase or decrease the microphone volume.
3. Turn the ECHO control on the rear panel of the device to increase the echo effect on the microphone.

Note: if you are placing the microphone next to the speaker, turn off the microphone. Otherwise, the speaker may feed back, causing a loud uncomfortable sound.

Placement

The speaker was designed to be placed on the floor, on any solid and stable surface, or on a tripod stand (tripod not included).

Note: if you will not be using the speaker for a long time, make sure it is turned off and unplugged.

Remote control

1. Standby mode ON/OFF
2. Select input
3. Sound modes
4. Volume up
5. play/pause
6. Music playback: Next track, FM: + 0.1 mHz (press)/Next FM channel (hold)
7. Repeat mode
8. Select track from USB and SD/ Select FM channel
9. Scan FM channels
10. Volume down
11. Music playback: previous track, FM: - 0.1 mHz (press)/previous FM channel (hold)
12. Mute
