- Page 1 Moxa Industrial Video Encoder VPort 451 Series Quick Installation Guide First Edition, March 2010 © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan, R.O.C. TEL: +886-2-8919-1230...
-
Page 2: Package Checklist
Overview The VPort 451 is a 1-channel industrial video encoder with MPEG4 and MJPEG video compression algorithm that provides a maximum of three video streams (two MPEG4, one MJPEG) simultaneously. The video streams can be used for different purposes, such as viewing, recording, and analyzing. The low latency (<200 milliseconds) of the VPort 451 makes it an optimal solution for mission-critical video applications, which require real-time video display. - Page 3 • Supports standard RTSP (Real-time streaming protocol) for easy integration. • Supports multicast (IGMP) protocols for efficient network transmission. • Supports QoS (TOS) for priority transmission. • Supports SNMP V1/V2c/V3 for network management. • Built-in web server and RS-232 console for remote access and configuration.
- Page 4 NOTE If you are interested in SoftNVR-IA IP surveillance software, please go to Moxa’s website (www.moxa.com) to download the trial version. - 4 -...
- Page 5 VPort 451 Panel Layout Grounding screw Top Panel View RS-232 console port Hardware reset button 8-pin terminal block for Relay RS-232 CONSOLE 1, Relay 2, and power input 1 (PWR1) 6-pin terminal block for DI 1, DI 2, power input 2 (PWR2) Heat dissipation orifices LEDs for STAT, PWR1, PWR2, FAULT...
-
Page 6: First-Time Installation And Configuration
If one of the power inputs fails, the FAULT LED will light up in red if the power failure alarm is enabled. NOTE The VPort 451 series supports power input specifications of 12-32 VDC for 12/24 VDC power input, or 18-30 VAC for 24 VAC power input (note that this is different from Moxa EDS switch’s... - Page 7 Step 4: Connecting motorized PTZ cameras and serial devices The VPort 451 has two RS-232/422/485 ports. One is a COM PORT with DB9 male connector, and the other is a PTZ PORT with 5-pin terminal block connector. Both ports can be used for connecting PTZ control cables for controlling PTZ cameras over the TCP/IP network.
- Page 8 NOTE After powering on the VPort 451, wait a few seconds for the POST (Power On Self Test) to run. The IP address will be assigned when the 10/100 Mbps NETWORK LED blinks. Using the Moxa VPort and EtherDevice Configurator Utility (edscfgui.exe) 1.
- Page 9 3. When the search has ended, the Model Name, MAC address, and IP address of the EDS switches and VPorts will be listed in the Utility window. NOTE Broadcast Search can only search for devices connected to the same LAN subnet as the VPort. If your devices are located on a different LAN subnet, use the “Specify IP Address”...
- Page 10 Step 7: Install the ActiveX Control Plug-in A security warning message will appear the first time you access the VPort’s web-based manager. The message is related to installing the VPort AcitveX Control component to your PC or notebook. Click on Yes to install this plug-in to enable the ability to view video in the IE web browser.
- Page 11 Step 9: Accessing the VPort’s System Configuration Click on System Configuration to access the overview of the system configuration to change the configuration. Model Name, Server Name, IP Address, MAC Address, Firmware Version, and LED Status appear in the green bar near the top of the page. Use this information to check the system information and installation.
-
Page 12: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) 8.7 mm 99.0 mm (3.9 in) (0.3 in) 27.5 mm 9.6 mm (1.1 in) (0.4 in) VIDEO VPort 451 45.8 mm (1.8 in) 105.0 mm (4.1 in) 53.0 mm (2.1 in) 113.8 mm (4.5 in) 9.3 mm (0.37 in) 30.5 mm (1.2 in) -
Page 13: Wall Mounting (Optional)
Wall Mounting (optional) For some applications, you will find it convenient to mount the VPort 451 on a wall, as illustrated below. STEP 1: Remove the aluminum DIN-Rail attachment plate from the VPort 451, and then attach the wall mount plates, as shown in the diagrams below. plate ⇒... -
Page 14: Wiring Requirements
Wiring Requirements WARNING Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa VPort 451. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum allowable current for each wire size. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your equipment. -
Page 15: Wiring The Redundant Power Inputs
Wiring the Redundant Power Inputs The VPort 451 has two sets of power input, power input 1 and power input 2, which are located on the 6-pin and 8-pin terminal block connectors. Top and front views of the terminal block connectors are shown here. - 15 -... -
Page 16: Wiring The Digital Inputs
ATTENTION The current and power capacity of the relay output is a maximum of 24 VDC @ 1A. You should be careful not to exceed this power specification. Wiring the Digital Inputs The VPort 451 has four sets of digital input, DI1, DI2, DI3 and DI4. -
Page 17: 10/100Baset(X) Ethernet Port Connection
10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) port located on the VPort 451’s front panel is used to connect to Ethernet-enabled devices. Pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports are illustrated below, along with cable wiring diagrams for straight-through and cross-over Ethernet cables. - Page 18 SC-Port Pinouts SC-port to SC-port Cable Wiring Cable Wiring COM Port A COM PORT is located on the front panel for connecting a PTZ motorized camera or serial device. The COM port transmits RS-232 or RS-422/485 signals over the TCP/IP network. Users can use this COM port (DB9 male connector) to monitor data or control a serial device, or for the control of a PTZ motorized camera.
-
Page 19: Sd Card Slot
PTZ port A PTZ port is located on the VPort 451’s front panel. The port is used to connect a PTZ motorized camera or device so that the camera or device can be controlled from the VPort over the IP network. The PTZ port supports RS-232 or RS-422/485 signals through a terminal block. -
Page 20: Led Indicators
NOTE Follow these steps to remove the SD card: Step1: Open the upper case. Step2: Wait a few seconds to allow the SD card to complete existing file storing activity. Step3: If the SD LED indicator is lighted in green, it means the unmounting of the SD card was successful, and you can take out the SD card. -
Page 21: Hardware Reset
No serial data is transmitting. SD card is mounted correctly and is ready to use. GREEN Error in mounting SD card. Flash No SD card in the slot. Hardware Reset A recessed RESET button is provided for restoring the system to the factory default settings. - Page 22 port, or 1 100BaseFX fiber port (SC connector) Optical Fiber: 100BaseFX Multi Mode Single Mode 1300 nm 1310 nm Wavelength -10 dBm 0 dBm Max. TX -20 dBm -5 dBm Min. TX RX Sensitivity -32 dBm -34 dBm Link Budget 12 dB 29 dB 5 km...
- Page 23 Environmental Operating Temperature 0 to 60°C (32 to 140°F) -40 to 75°C (-40 to 167°F) for -T models Storage Temperature -40 to 85°C (-40 to 185°F) Ambient Relative 5 to 95% (non-condensing) Humidity Regulatory Approvals Safety UL 508 (Pending) FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), Level 3 EN61000-4-3 (RS), Level 3 EN61000-4-4 (EFT), Level 3...
- Page 24 DirectX 9.0c Software Bundled Free VPort SDK PLUS Includes CGI commands and ActiveX Control for customized applications or system integration for third-party developers Technical Support Contact Information www.moxa.com/support Moxa Americas: Moxa China (Shanghai office): Toll-free: 1-888-669-2872 Toll-free: 800-820-5036 Tel: +1-714-528-6777 Tel: +86-21-5258-9955 Fax:...
