- Page 1 Moxa Industrial Video Encoder VPort 354 Series Quick Installation Guide Third Edition, November 2011 2011 Moxa Inc. All rights reserved. P/N: 1802003540012...
-
Page 2: Package Checklist
Overview The VPort 354 is a high performance, 4-channel industrial video encoder that provides up to 4 CIF full frame rate performance (NTSC: 704 x 480 @ 30 FPS and PAL: 704 x 576 @ 25 FPS) for each channel, and supports a dual MJPEG/MPEG4 algorithm, making it especially well-suited for use with distributed surveillance systems in critical industrial applications. - Page 3 • Supports one SD card slot (SDHC interface) for recording video on the SD card if the network is down. • Two auto-sensing 10/100BaseT(X) Ethernet port or 100BaseFX • (SC connector) for cascade link or port redundancy. • Allows a maximum of 8 unicast and 4 multicast output video streams at the same time.
- Page 4 VPort 354 Panel Layout 1. Grounding screw 2. RS-232 console port 3. Hardware reset button 4. 8-pin terminal block for Relay 1, Relay 2, and power input 2 (PWR2) 5. 10-pin terminal block for DI 1, DI 2, DI 3, DI 4, power input 1 (PWR1) 6.
-
Page 5: First-Time Installation And Configuration
FAULT LED will light up in red if the power failure alarm is enabled. NOTE The VPort 354 series support power input specifications of 12-32 VDC for 12/24 VDC power input, or 18-30 VAC for 24 VAC power input (note that this is different from Moxa EDS switch’s 12-45... - Page 6 Step 4: Connecting motorized PTZ cameras and serial devices. The VPort 354 has 2 RS-232/422/485 ports. One is a COM PORT with DB9 male connector, and the other is a PTZ PORT with 5-pin terminal block connector. Both ports can be used for connecting PTZ control cables for controlling PTZ cameras over the TCP/IP network.
- Page 7 NOTE After powering on the VPort 354, wait a few seconds for the POST (Power On Self Test) to run. The IP address will be assigned when the 10 or 100 Mbps NETWORK LED blinks. Using the Moxa Ethernet Switch And Video Server Configurator Utility (edscfgui.exe) 1.
- Page 8 3. When the search has ended, the Model Name, MAC address, and IP address of the EDS switches and VPorts will be listed in the Utility window. NOTE Broadcast Search can only search for devices connected to the same LAN subnet as the VPort. If your devices are located on a different LAN subnet, use the “Specify IP Address”...
- Page 9 NOTE For Windows XP SP2 or above operating systems, the ActiveX Control component will be blocked for system security reasons. In this case, the VPort’s security warning message window may not appear. Users should unblock the ActiveX control function or disable the security configuration to enable the installation of VPort’s ActiveX Control component.
- Page 10 For details of each configuration, check the User’s Manual on the software NOTE After accessing the VPort 354’s web-based manager, administrators should access System Configuration System Account to set up the administrator’s password and enable the authentication function. The administrator account name is admin.
-
Page 11: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) DIN-Rail Mounting The aluminum DIN-Rail attachment plate should already be attached to the back panel of the VPort 354 when you take it out of the box. If you need to reattach the DIN-Rail attachment plate to the VPort 354, make sure the stiff metal spring is situated towards the top, as shown in the figures below. -
Page 12: Wall Mounting (Optional)
Wall Mounting (optional) NOTE Wall-mounting kit (WK-46) ordered separately For some applications, you will find it convenient to mount the VPort 354 on a wall, as illustrated below. STEP 1: Remove the aluminum DIN-Rail attachment plate from VPort 354, and then attach the wall mount plates, as shown in the diagrams below. -
Page 13: Wiring Requirements
Wiring Requirements WARNING Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa VPort 354. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your equipment. -
Page 14: Wiring The Redundant Power Inputs
Wiring the Redundant Power Inputs The VPort 354 has two sets of power input, power input 1 and power input 2, which are located on the 10-pin and 8-pin terminal block connectors. Top and front views of the terminal block connectors are shown here. STEP 1: Insert the negative/positive DC or AC wires into the V-/V+ terminals. -
Page 15: Wiring The Digital Inputs
Wiring the Digital Inputs VPort 354 has four sets of digital input, DI1, DI2, DI3 and DI4. Each DI consists of two contacts of the 10-pin terminal block connector on VPort’s top panel. Top and front views of one of the terminal block connectors are shown here. -
Page 16: 10/100Baset(X) Ethernet Port Connection
10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on the VPort 354’s front panel are used to connect to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports, and also show cable wiring diagrams for straight-through and cross-over Ethernet cables. - Page 17 SC-Port Pinouts SC-port to SC-port Cable Wiring NOTE The 2 Ethernet ports on the VPort 354’s front panel can be used as cascade links or to provide port redundancy. When used as cascade links, you will need to calculate the number of video streams in order to optimize the transmission bandwidth.
-
Page 18: Sd Card Slot
PTZ port A PTZ port is located on the VPort 354’s front panel. The port is used to connect a PTZ motorized camera or device so that the camera or device can be controlled from the VPort over the IP network. The PTZ port supports RS-232 or RS-422/485 signals through a terminal block. -
Page 19: Led Indicators
NOTE Follow these steps to remove the SD card: Open the upper case. The SD LED indicator will light up Step1: in red. Wait a few seconds to allow the SD card to complete Step2: existing file storing activity. If the SD LED indicator light is off, it means the Step3: unmounting of the SD card was successful, and you can take out the SD card. -
Page 20: Hardware Reset
Hardware Reset A recessed RESET button is provided for restoring the system to the factory default settings. When the system fails to install properly, or operates abnormally, use the RESET button located on the top panel of the VPort 354 to restore the factory defaults. To do this, use a pointed object such as a straightened paper clip or toothpick, to depress the reset button continuously. - Page 21 Serial Port COM port 1 RS-232 or RS-422/485 port, DB9 male connector, 115.2 Kbps max. baudrate PTZ port 1 port, RS-232 or RS-422/485 terminal block connector, 115.2 Kbps max. baudrate Console port 1 RS-232 RJ45 port GPIO Digital Inputs 4, max. 8 mA Low: +13V to +30V High: -30V to +3V Relay Output...
- Page 22 Alarm Features • Video Motion detection with sensitivity tuning • Daily repeat timing schedule • JPEG snapshots for pre/trigger/post alarm images • Automatic transfer of stored images via email or FTP with event-triggered actions • HTTP Action setting for customized alarm messages being sent via HTTP Event Server and CGI events PAN/TILT/ZOOM •...
