  • Page 1 *Applicable models list is subject to change without notice. ©EXCELL PRECISION CO., LTD. 2017. All rights reserved worldwide. The information contained herein is the property of EXCELL PRECISION CO., LTD. and is supplied without liability for errors or omissions. No part may be reproduced or used except as authorized by contract or other written permission.

  • Page 2: Table Of Contents

    EXCELL PRECISION CO., LTD. TABLE OF CONTENTS INSTRUCTION FOR USE ....................2 PREPARATION BEFORE USING..................2 CHAPTER 1 PRODUCT INSTRUCTION................4 1-1 I ......................4 NTRODUCTION 1-2 E ....................... 4 RROR ESSAGES 1-3 S ......................4 CREEN ISPLAY 1-4 P ......................

  • Page 3: Instruction For Use

    EXCELL PRECISION CO., LTD. Thank you for purchasing Price Computing Scale. In order to operate smoothly, to last the durability, and to reduce the chance of breakdown for this product, please read this Manual carefully. Precautions for Use 1. In order to prevent the scale from dust and static electricity, please fix the dustproof cover on the scale with double-sided adhesive.
  • Page 4 EXCELL PRECISION CO., LTD. Due to the storage battery adopt the advanced free-maintaining technique, customers need not to replenish electrolyte. The scale should be recharged every 3 months to prevent failure of the internal rechargeable battery. 1. The battery should be charged for 8~10 hours.

  • Page 5: Chapter 1 Product Instruction

    EXCELL PRECISION CO., LTD. Chapter 1 Product Instruction 1-1 Introduction 1. High performance A/D converter 2. Linearity calibration function 3. One group of RS232 output 4. Adapter or rechargeable battery 5. LCD display 6. Battery low protection (When battery voltage is lower than system voltage, the system will cut the power off automatically to ensure its stable and accuracy.)

  • Page 6: Power Supply

    EXCELL PRECISION CO., LTD. 3. Total Price 6 digits in total display the total price of the objects on platter or the accumulation. Symbol Display 1. Z “Zero” indication. 2. T “Tare” indication. 3. M+ : “Accumulation” indication. “Power” indication.

  • Page 7: Chapter 2 Keyboard Function

    EXCELL PRECISION CO., LTD. Chapter 2 Keyboard Function 0 ~ 9 : Number key. Press the keys to input the numbers (0 ~ 9) and to set unit price. CE : Press the key to clear the old unit price and then input the new one if you would like to change the unit price (If the unit price has been input for 3 seconds, you can input the new one immediately).

  • Page 8: Chapter 3 Operation Instruction

    EXCELL PRECISION CO., LTD. Chapter 3 Operation Instruction 3-1 Internal Value Display Mode Press Z key, when the display show “ ” ,then, press CE key immediately. The display will show internal value. Press 0 to exit the internal value mode and return to the weighing mode.

  • Page 9: External Weight Calibration

    EXCELL PRECISION CO., LTD. 3-4 External Weight Calibration Steps： 1. Make sure the scale backs to zero and is in “kg” mode. 2. Press MC key and do not release, the then press . key to show “ ” , the weight display “ .

  • Page 10: Chapter 4 Rs232 Function Setting(Option)

    EXCELL PRECISION CO., LTD. Chapter 4 Function Settings Press MC key do not release, and turn power on to enter function setting mode. RS-232* Baud Rate  Transmission Mode ( RS-232* )  press T key to circulate selection function.

  • Page 11: F2  Transmission Mode ( Rs-232 )

    EXCELL PRECISION CO., LTD. 4-2 F2     Transmission Mode (RS-232) (optional) Weight Unit Price Total Price $/kg Press number key 0 , 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 to choose 0,1,2,3,4,5,6,7,8 in order 0 ...
  • Page 12 EXCELL PRECISION CO., LTD. When F2 setting is “0 ”, the RS232 format is as below. Press M+ to print 10.005kg 0.500kg 50/kg 500.25 Press to print 20pcs 10/pcs Press to print ← When recalled the returned good, TOTAL NUMBER 002 it will print the total price.
  • Page 13 EXCELL PRECISION CO., LTD. RS232 DATA FORMAT Stable transmission Continuous transmission (1) Weight unit is g. 10 11 12 13 14 15 16 17 ± HEAD HEAD DATA UNIT CR (2) Weight unit is kg/lb 10 11 12 13 14 15 16 17 18 kg/lb ±...
  • Page 14 EXCELL PRECISION CO., LTD. Example of Transmission: Data format for RS-232 continuous transmission are as below. 1. The gross weight (+0.876 kg) shown as below, after stable: (under no tare or pre-tare mode) 0D 0A HEAD HEAD DATA UNIT 2. The net weight (-1.568lb) shows as below, after unstable: (under tare or pre-tare mode)

  • Page 15: Appendix: 7-Segment Display Characters

    EXCELL PRECISION CO., LTD. Appendix: 7-Segment Display Characters Number Display Letter Display Letter Display ° C 01014012 ZSME100000134...
