Page 1: User Manual
EXCELL PRECISION CO., LTD Weighing Scale User Manual Weighing ZSME300000036... -
Page 3: Preparation Before Operation
3. When turning on the scale, do not place any object on the platter. 4. When operating the scale, place the object on the center of the platter. For the accuracy of weighing, do not place the object over the range of the platter. -
Page 4: Keyboard Description
EXCELL PRECISION CO., LTD Keyboard Description “UNITS” Press the key to select the weighing unit “kg” or “lb.” UNITS ”ESC” Return function. PRESET Preset function for weight. M+ : Accumulation function for weight. : ”TARE” TARE/← PRETARE : Pre-tare function. -
Page 5: Weighing Function
1. After turning on the scale, press display indications “kg” or “lb”. 2. After turning off the scale, the scale will memorize the weighing unit. When turning on the scale next time, the weighing unit used previously will be recalled directly. - Page 6 EXCELL PRECISION CO., LTD Example: “Lower Limit” Presetting (lower limit 10d, d=division) ex.: lower limit = 20kg. Press PRESET Press ZERO/→ once, the screen displays Press BL/↑ twice, the screen displays Meanwhile, if pressing “Upper Limit” Presetting (upper limit Press ENTER once, the screen displaysï...
- Page 7 EXCELL PRECISION CO., LTD 4 Single Point Presetting Lower limit only Method (I) After finished presetting lower limit, the screen displaysï PRESET once again. If the screen displays presetting” is completed. Method (II) After finished presetting lower limit, upper limit and buzzer, press...
- Page 8 EXCELL PRECISION CO., LTD Note 1 0 = Buzzer beeps when being stable; LCD indication lights up. 1 = Buzzer beeps when being stable; LCD indication lights up without stable determination. 2 = Buzzer beeps and LCD indication lights up without stable determination.
- Page 9 EXCELL PRECISION CO., LTD LCD Indication: ïLOWð ïOKð ïHIGHð 10d Lower Limit Upper Limit After entering into the presetting mode, if intended to abort, press 2. Setting Value Recall Press PRESET and then Press RECALL Press RECALL Press RECALL again 3.
- Page 10 “total count accumulation”. (4). Zero Function If zero drift happens during operating the scale, which means no objects on platter, but the screen displays tiny weight value, press the screen will display the zero (à0ß) indication.
- Page 11 Œ Place the container on platter. After being stable, press re-zero. The screen will display net weight (Net) indication. • Place the object into the container, and the scale will display the net weight of it. Ž “Tare value” clearing Remove both the container and the object on the platter;...
- Page 12 Input the weight of container. After finished, the screen displays the negative value of the container, and the net weight (Net) and pre-tare (PT) indications light • Place both the object and container on platter, and the scale displays the net weight of it.
-
Page 13: Appendix: 7 Segment Display Characters
EXCELL PRECISION CO., LTD Appendix: 7 Segment Display Characters 7 segments Digit letter Weighing 7 segments Alphabet letter 7 segments Alphabet letter ZSME300000036...
