ANTENNAS
Chapter 4 – Antennas

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate
antennas meeting the given specifications.
The antenna system is defined as the UFL connection point from the device to the specified cable specifications
and specified antenna specifications.

PTCRB Requirements

There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with
similar in-band and out-of-band radiation patterns and maintain the same specifications.

LTE Antenna Information

The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer:
Description:
Model Number:
MultiTech Part Number:
MultiTech ordering information:
Model
ANLTE3-2HRA
ANLTE3-10HRA
ANLTE3-50HRA

Antenna Specifications

Category
Frequency Range
Power Rating
VSWR
Gain
Radiating Element
16
EAD Ltd.
LTE Antenna with SMA-Male Connector
WTR7270
45009760L
Quantity
2
10
50
Description
690-960 MHz
1710-2700 MHz
10 W
< 2.0:1
1 dBi
1/2 wave element
®
SocketModem Cell MTSMC-LAT3 Device Guide
