SMARTBOX Installation

Minimum Clearance for Proper Mounting

SMARTBOX™ Controller for HONEYWELL™ Wind Turbine WT6500 Owner's Manual - Rev14
allow for at least
300 mm (12 in)
clearance.
Figure 2.3 Minimum Clearance for Proper Mounting
EQUIPMENT DAMAGE
Never install the SMARTBOX™ Controller where it is
exposed to salt water spray. Exposure to salt water will void
the warranty and may cause a shock hazard.
EXPLOSION/CORROSION DAMAGE
To reduce the risk of corrosion from hydrogen-sulfide
gas vented by batteries, do not install the SMARTBOX™
Controller in sealed compartments containing batteries.
Failure to follow this warning may result in death, personal
injury or property damage.
Get other manuals https://www.bkmanuals.com
allow for at least 150 mm
(6 in) clearance.
allow for at least
300 mm (12 in)
clearance.
allow for at least 150 mm
(6 in) clearance.
10
allow for at least
508 mm (20 in)
clearance.
