- Page 1 Super Booster Plus for HDMI 1.3 U S E R M A N U A L www.gefen.com...
- Page 2 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Super Booster Plus for HDMI 1.3 is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Descriptions Connecting and Operating Super Booster Plus for HDMI 1.3 Auto Equalization Specifi cations Warranty... -
Page 4: Introduction
Attach one end of your long HDMI cable to the HDMI source, then connect the other end of the long cable, near the display, to the input on the Gefen Super Booster Plus for HDMI 1.3. Connect the Display to the Super Booster Plus for HDMI 1.3 by attaching a cable between the display’s HDMI input and the output on the Super... -
Page 5: Features
FEATURES Features • Perfect digital high defi nition video sent over long stretches of HDMI cables • Locate an HDMI display up to 200 feet away from any HDTV source • Supports resolutions up to 1080p, 2K, and 1920 x 1200 •... - Page 6 PANEL LAYOUT Front Panel Power LED Manual EQ Indicator Adjustment HDMI In Back Panel +5V DC In HDMI Out...
-
Page 7: Connecting And Operating Super Booster Plus For Hdmi
CONNECTING AND OPERATING THE SUPER BOOSTER PLUS FOR HDMI 1.3 Connect the long HDMI cable from the source into the “HDMI In” on the front of Super Booster Plus for HDMI 1.3. Super Booster Plus for HDMI 1.3 is placed next to your display to regenerate the HDMI signal. -
Page 8: Auto Equalization
AUTO EQUALIZATION Remove the silver Remove the silver tape to expose the tape to expose the Dip Switch Bank Dip Switch Bank Manual EQ Long Cable Manual EQ Long Cable Auto EQ ON Auto EQ ON Manual EQ Short Cable Manual EQ Short Cable Dip Switch 2 can be used to turn on the automatic equalization function. -
Page 9: Specifications
SPECIFICATIONS Video Amplifi er Bandwidth ................225 MHz Input Video Signal ................... 1.2 Volts p-p Input DDC Signal ................5 Volts p-p (TTL) Single Link Range ................ 1080p/1920 x 1200 HDMI Connector ................. type A 19 pin female Dimensions ................1.6”W x 1.1”H x 1.8”D Shipping Weight ....................
