Omada L2+ Managed Switch
LEDs
For SG3210X-M2
LED
PWR
SYS
2.5G
1G/100M
SFP+
For SG3210XHP-M2
LED
Indication
On: The switch is powered on.
PWR
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
On: The remaining PoE power is ≤ 7 W.
PoE Max
Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes.
Off: The remaining PoE power is > 7 W.
Green: All the fans work properly.
FAN
Yellow: Not all the fans work properly.
Green On: Running at 2.5 Gbps, but no activity.
Green Flashing: Running at 2.5 Gbps and transmitting or receiving data.
Speed
Yellow On: Running at 100/1000 Mbps, but no activity.
Yellow Flashing: Running at 100/1000 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
02
Introduction
Indication
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
Flashing: The switch works properly.
On or Off: The switch works improperly.
On: Running at 2.5 Gbps, but no activity.
Flashing: Running at 2.5 Gbps and transmitting or receiving data.
Off: Running at 1000/100 Mbps or no device is linked to the corresponding port.
Green On: Running at 1 Gbps, but no activity.
Green Flashing: Running at 1 Gbps and transmitting or receiving data.
Yellow On: Running at 100 Mbps, but no activity.
Yellow Flashing: Running at 100 Mbps and transmitting or receiving data.
Off: Running at 2.5 Gbps or no device is linked to the corresponding port.
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
