10) Wiring Examples

2x LNB
(QUATTRO)
TERR ANTENNA
PA12
MS9/9+6ECU-4
9x cable
MS9/9+6ECU-4
9x cable
MS9/9+6ECU-4
9x cable
MS9/6ECU-4
More wiring examples are shown at the manufacturer's website.
