  • Page 1 Entrance and Exit Capture Camera User Manual...
  • Page 2 With the philosophy of "Technology for the Good", Hikvision requests that every end user of video technology and video products shall comply with all the applicable laws and regulations, as well as ethical customs, aiming to jointly create a better community.
  • Page 3 Entrance and Exit Capture Camera User Manual control, selecting a suitable network environment (the Internet or Intranet) where video products are connected, establishing and constantly optimizing network security. Video products have made great contributions to the improvement of social security around the ●...
  • Page 4 WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,...
  • Page 5 Entrance and Exit Capture Camera User Manual DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
  • Page 6 Entrance and Exit Capture Camera User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 7 Entrance and Exit Capture Camera User Manual Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
  • Page 8 Entrance and Exit Capture Camera User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, could Caution result in equipment damage, data loss, performance degradation, or...
  • Page 9 Entrance and Exit Capture Camera User Manual Safety Instruction Regulatory Information This is a class A product and may cause radio interference in which case the user may be required to take adequate measures. Laws and Regulations Use of the product must be in strict compliance with the local laws and regulations. Please shut down the device in prohibited area.
  • Page 10 Entrance and Exit Capture Camera User Manual DO NOT expose the device to extremely hot, cold, or humidity environments. For temperature ● and humidity requirements, see device specification. No naked flame sources, such as lighted candles, should be placed on the equipment. ●...
  • Page 11 Entrance and Exit Capture Camera User Manual The scrapped battery should be discarded in compliance with the local laws and regulations. If ● there are no corresponding laws or regulations, throw it in a hazardous trash can. DO NOT pierce the battery or shorten the electrodes, or it may cause explosion or fire hazard. ●...

  • Page 12: Table Of Contents

    Entrance and Exit Capture Camera User Manual Contents Chapter 1 Introduction ....................... 1 1.1 Introduction ........................... 1 1.2 Key Feature ..........................1 Chapter 2 Activation and Login ....................2 2.1 Activation ..........................2 2.1.1 Default Information ...................... 2 2.1.2 Activate via SADP ......................2 2.1.3 Activate via Web Browser .....................
  • Page 13 Entrance and Exit Capture Camera User Manual Chapter 5 Network Configuration ..................... 25 5.1 Set IP Address ........................25 5.2 Connect to Platform ......................27 5.2.1 Connect to ISUP Platform ................... 27 5.2.2 Connect to Guarding Vision ..................28 5.3 Set DDNS ..........................29 5.4 Set IEEE 802.1X ........................
  • Page 14 Entrance and Exit Capture Camera User Manual 8.5 Set HTTPS ..........................49 8.5.1 Create and Install Self-signed Certificate ..............49 8.5.2 Install Authorized Certificate ..................49 Chapter 9 Maintenance ......................50 9.1 View Device Information ...................... 50 9.2 Log ............................50 9.2.1 Enable System Log Service ..................

  • Page 15: Chapter 1 Introduction

    Entrance and Exit Capture Camera User Manual Chapter 1 Introduction 1.1 Introduction Entrance and exit capture camera (hereinafter referred to as device) integrates multiple functions including video collection, smart video compression, network transmission, etc. It can be used with other devices (vehicle detector or barrier gate) to realize vehicle management and control, light supplement, capture, etc.

  • Page 16: Chapter 2 Activation And Login

    Get the SADP software from the supplied disk or the official website ( https:// ● www.hikvision.com/ ), and install it according to the prompts. The device and the computer that runs the SADP tool should belong to the same network ●...

  • Page 17: Activate Via Web Browser

    Entrance and Exit Capture Camera User Manual Figure 2-1 Activate via SADP Status of the device becomes Active after successful activation. 5. Modify IP address of the device. 1) Select the device. 2) Change the device IP address to the same network segment as your computer by either modifying the IP address manually or checking Enable DHCP.

  • Page 18: Login

    Entrance and Exit Capture Camera User Manual Caution STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product.

  • Page 19: Chapter 3 Capture Configuration

    Entrance and Exit Capture Camera User Manual Chapter 3 Capture Configuration 3.1 Quick Configuration 3.1.1 Set Basic Parameters When the I/O coils have been laid and the device has been connected to trigger capture in the site, you can set the basic parameters in quick configuration to realize capture quickly. Before You Start The device position has been adjusted.
  • Page 20 Entrance and Exit Capture Camera User Manual Icon Function Icon Function Hold it to realize zoom +. Hold it to realize focus -. Hold it to realize zoom -. Click it to realize one-touch focus. Hold it to realize focus +. Click it to initialize the lens, and all the parameters will restore to default.

  • Page 21: Detailed Configuration

    Entrance and Exit Capture Camera User Manual 3.2 Detailed Configuration 3.2.1 Set Application Mode If you want to trigger capture of the passing vehicle information at the entrance or exit, set the application mode. Before You Start The device has been installed at the specific location, and the lens has been debugged. Steps 1.
  • Page 22 Entrance and Exit Capture Camera User Manual Video Detection Select it when video recognition mode is applied at the site. The capture mode is Strobe Light Mode. I/O Coil Select it when the device has been connected to I/O signal. RS485 Select it when the device has been connected to RS-485 devices.

  • Page 23: Set Capture Parameters

    Entrance and Exit Capture Camera User Manual 3.2.2 Set Capture Parameters Set License Plate Recognition Parameters When there are vehicles of different types passing from different directions, set the license plate recognition parameters. Steps 1. Go to Configuration → Device Configuration → Capture Parameters → License Parameters . Figure 3-3 Set License Plate Recognition Parameters 2.
  • Page 24 Entrance and Exit Capture Camera User Manual Figure 3-4 Set Supplement Light Parameters 2. Set Duty Ratio/Brightness. Duty Ratio/Brightness It is the time occupation of the high level in a certain period. The higher the duty ratio, the brighter the supplement light. High duty ratio will cut life span of the supplement light. 3.
  • Page 25 Entrance and Exit Capture Camera User Manual Steps Note Some models do not support vehicle features recognition. The actual device prevails. 1. Go to Configuration → Device Configuration → Capture Parameters → Vehicle Feature . Figure 3-5 Set Vehicle Feature Parameters 2.
  • Page 26 Entrance and Exit Capture Camera User Manual Figure 3-7 Set Capture Overlay 3. Set the font size, color, overlay position, etc. Percentage It is the percentage that the overlaid information occupies on the picture. Overlay Number Zeroizing When the overlaid number digits are smaller than the fixed digits, 0 will be overlaid before the overlaid number.

  • Page 27: View Real-Time Picture

    Entrance and Exit Capture Camera User Manual Note The overlay information varies with different models. The actual device prevails. 5. Set the overlay information. Type You can edit the type. Overlay Information For some information types, you can edit the detailed information. Overlay Position Check it, and the current information will be displayed from a new line.
  • Page 28 Entrance and Exit Capture Camera User Manual Figure 3-8 Real-Time Picture 3. You can do the following operations on this interface. - Select the arming mode. Level 1 Arming can only connect one client or web. The uploaded pictures will not be stored in the storage card. The pictures in the storage card will be uploaded to the level 1 arming.

  • Page 29: Search Picture

    Entrance and Exit Capture Camera User Manual - For the supplement light parameters settings, refer to "Set Flash Light Parameters" for details. For the image parameters settings, refer to "Set Video Parameters" for details. For the entrance settings, refer to "Set Barrier Gate Linkage" for details. 3.4 Search Picture You can search the captured pictures stored in the storage card and export the pictures you need.
  • Page 30 Entrance and Exit Capture Camera User Manual Note If you have set level 1 arming for the device, the captured pictures will not be saved in the storage card. Go to the saving path of scene pictures to view them. You can go to Configuration →...

  • Page 31: Chapter 4 Peripheral Device Linkage

    Entrance and Exit Capture Camera User Manual Chapter 4 Peripheral Device Linkage 4.1 Set Barrier Gate Linkage If a barrier gate has been connected to the device, you can link barrier gate to realize the control and management of the vehicles at the entrance or exit. 4.1.1 Set Allowlist and Blocklist Set allowlist and blocklist if you want to control the passing vehicles at the entrance or exit via the barrier gate.
  • Page 32 Entrance and Exit Capture Camera User Manual Figure 4-1 Set Allowlist and Blocklist 3. You can search, modify, delete, import, or export the allowlist and blocklist. Search Select the search type, or enter the keywords. Click Search. The searched vehicle information will be listed below.

  • Page 33: Control Barrier Gate

    Entrance and Exit Capture Camera User Manual 4.1.2 Control Barrier Gate Link the barrier gate to realize the control and management of the vehicles at the entrance or exit. Steps 1. Go to Configuration → Device Configuration → Entrances and Exits → Entrance and Exit . Figure 4-2 Control Barrier Gate 2.

  • Page 34: Set Lcd

    Entrance and Exit Capture Camera User Manual Note Some models do not support this function. The actual device prevails. 5. Set the relay function. Note The supported number of relays varies with different models. Relay 1 corresponds to the 1A and 1B of the terminal.
  • Page 35 Entrance and Exit Capture Camera User Manual Figure 4-3 Set LCD 2. Select Control Mode and Time Format. 3. Set the display content. 1) Click + to add a row of idle title, passing vehicle title, or custom content according to your needs.
  • Page 36 Entrance and Exit Capture Camera User Manual The duration from the end of displaying passing vehicle information to the start of displaying idle information. 4. Optional: If the device has been connected to the platform, you can check Display Free Space to display the number of the free parking spaces.

  • Page 37: Set Serial Port

    Entrance and Exit Capture Camera User Manual 4.3 Set Serial Port 4.3.1 Set RS-485 Set RS-485 parameters if the device has been connected to a vehicle detector or other RS-485 devices. Before You Start The corresponding device has been connected via the RS-485 serial port. Steps 1.
  • Page 38 Entrance and Exit Capture Camera User Manual Steps 1. Go to Configuration → Device Configuration → System Configuration → Serial Ports . 2. Click Advanced Settings. Figure 4-5 Set RS-232 3. Set Baud Rate, Data Bit, Stop Bit, etc. Note The parameters should be same with those of the connected device.

  • Page 39: Chapter 5 Network Configuration

    Entrance and Exit Capture Camera User Manual Chapter 5 Network Configuration 5.1 Set IP Address IP address must be properly configured before you operate the device over network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting to each other.
  • Page 40 Entrance and Exit Capture Camera User Manual The device automatically gets the IPv4 parameters from the network if you check DHCP. The device IP address is changed after enabling the function. You can use SADP to get the device IP address.

  • Page 41: Connect To Platform

    Entrance and Exit Capture Camera User Manual 5.2 Connect to Platform 5.2.1 Connect to ISUP Platform ISUP (EHome) is a platform access protocol. The device can be remotely accessed via this platform. Before You Start Create the device ID on ISUP platform. ●...

  • Page 42: Connect To Guarding Vision

    Entrance and Exit Capture Camera User Manual 5.2.2 Connect to Guarding Vision The device can be remotely accessed via Guarding Vision. Before You Start Connect the device to the Internet. ● Set the IP address, subnet mask, gateway, and DNS server of the LAN. ●...

  • Page 43: Set Ddns

    Entrance and Exit Capture Camera User Manual 5.3 Set DDNS You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can be mapped to a domain name resolution server to realize the network access via domain name. Before You Start Register the domain name on the DDNS server.

  • Page 44: Set Ieee 802.1X

    Entrance and Exit Capture Camera User Manual 5.4 Set IEEE 802.1X IEEE 802.1X is a port-based network access control. It enhances the security level of the LAN/ WLAN. When devices connect to the network with IEEE 802.1X standard, the authentication is needed.
  • Page 45 Entrance and Exit Capture Camera User Manual Go to Configuration → Device Configuration → System Configuration → Port for port settings. Figure 5-6 Set Port HTTP Port It refers to the port through which the browser accesses the device. For example, when the HTTP Port is modified to 81, you need to enter http://192.168.1.64:81 in the browser for login.

  • Page 46: Chapter 6 Record

    Entrance and Exit Capture Camera User Manual Chapter 6 Record 6.1 Set Storage Path 6.1.1 Set Memory Card If you want to store the files to the memory card, make sure you insert and format the memory card in advance. Before You Start Insert the memory card to the device.

  • Page 47: Set Ftp

    Entrance and Exit Capture Camera User Manual 6.1.2 Set FTP Set FTP parameters if you want to upload the captured pictures to the FTP server. Before You Start Set the FTP server, and ensure the device can communicate normally with the server. Steps 1.

  • Page 48: Set Listening Host

    Entrance and Exit Capture Camera User Manual 6.1.3 Set Listening Host The listening host can be used to receive the uploaded information and pictures of the device arming alarm. Before You Start The listening service has been enabled for the listening host, and the network communication with the device is normal.

  • Page 49: Set Quota

    Entrance and Exit Capture Camera User Manual Figure 6-4 Set Cloud Storage 2. Check Enable. 3. Set the server parameters. 1) Select Version. 2) Enter Access Server IP Address and Port No. 3) Enter accessKey and secretKey of the resource pool. 4) Enter the ID according to the storage area No.

  • Page 50: Set Record Schedule

    Entrance and Exit Capture Camera User Manual 6.3 Set Record Schedule Set record schedule to record video automatically during configured time periods. Before You Start Install the memory card, and you are recommended to set the video quota ratio as not 0. Steps 1.

  • Page 51: Local Configuration

    Entrance and Exit Capture Camera User Manual 6.4 Local Configuration Go to Configuration → Local Configuration to set the live view parameters and change the saving paths of videos, captured pictures, scene pictures, etc. Figure 6-6 Local Configuration Protocol Select the network transmission protocol according to the actual needs. Ensures complete delivery of streaming data and better video quality, yet the real-time transmission will be affected.
  • Page 52 Entrance and Exit Capture Camera User Manual Reserved. Feature Information Reserved. Record File Size Select the packed size of the manually recorded video files. After the selection, the max. record file size is the value you selected. Save record files to Set the saving path for the manually recorded video files.

  • Page 53: Chapter 7 Encoding And Display

    Entrance and Exit Capture Camera User Manual Chapter 7 Encoding and Display 7.1 Set Video Encoding Parameters Set video encoding parameters to adjust the live view and recording effect. When the network signal is good and the speed is fast, you can set high resolution and bitrate to ●...

  • Page 54: Set Image Parameters

    Entrance and Exit Capture Camera User Manual Video Quality When bitrate type is variable, 6 levels of video quality are selectable. The higher the video quality is, the higher requirements of the network bandwidth. Profile When you select H.264 or H.265 as video encoding, you can set the profile. Selectable profiles vary according to device models.
  • Page 55 Entrance and Exit Capture Camera User Manual Figure 7-1 Set General Parameters Figure 7-2 Set Video Image Parameters 2. Adjust the parameters. Saturation It refers to the colorfulness of the image color. Sharpness It refers to the edge contrast of the image. White Balance...
  • Page 56 Entrance and Exit Capture Camera User Manual It is the white rendition function of the device used to adjust the color temperature according to the environment. WDR Mode Wide Dynamic Range (WDR) can be used when there is a high contrast of the bright area and the dark area of the scene.

  • Page 57: Set Icr

    Entrance and Exit Capture Camera User Manual 3D DNR Digital Noise Reduction (DNR) reduces the noise in the video stream. In Normal Mode, the higher the 3D DNR Level is, the stronger the noise will be reduced. But if it is too high, the image may become fuzzy. In Expert Mode, set Spatial Intensity and Time Intensity.
  • Page 58 Entrance and Exit Capture Camera User Manual Before You Start Please check the video encoding type. ROI is supported when the video encoding type is H.264 or H.265. Steps 1. Go to Configuration → Device Configuration → Encoding and Storage → ROI . Figure 7-3 Set ROI 2.

  • Page 59: Set Osd

    Entrance and Exit Capture Camera User Manual 5) Select the fixed area that needs to be adjusted and drag the mouse to adjust its position. 6) Click Stop Drawing. 4. Enter Area Name and select ROI Level. Note The higher the ROI level is, the clearer the image of the detected area is. 5.
  • Page 60 Entrance and Exit Capture Camera User Manual 3. Set the display content. 1) Enter Display Name. 2) Check Display Date, and set the time and date format. 3) Check Display Week or Millisecond. 4. Optional: Check the display item(s) and enter the information in the text field(s). 5.

  • Page 61: Chapter 8 Safety Management

    Entrance and Exit Capture Camera User Manual Chapter 8 Safety Management 8.1 Manage User The administrator can add, modify, or delete other accounts, and grant different permissions to different user levels. Steps 1. Go to Configuration → Device Configuration → User Management . 2.

  • Page 62: Enable User Lock

    Entrance and Exit Capture Camera User Manual 3. Set Filtering Mode. Blocklist Mode The added IP addresses are not allowed to access the device. Allowlist Mode The added IP addresses are allowed to access the device. 4. Click Add, enter the IP address, and click Add. Figure 8-1 Set IP Address Filtering 5.

  • Page 63: Set Https

    Entrance and Exit Capture Camera User Manual 8.5 Set HTTPS 8.5.1 Create and Install Self-signed Certificate HTTPS is a network protocol that enables encrypted transmission and identity authentication, which improves the security of remote access. Steps 1. Go to Configuration → Device Configuration → System Configuration → HTTPS . 2.

  • Page 64: Chapter 9 Maintenance

    Entrance and Exit Capture Camera User Manual Chapter 9 Maintenance 9.1 View Device Information Basic Information and Algorithms Library Version Go to Configuration → Device Configuration → System Configuration → Device Information to view the basic information and algorithms library version of the device. You can edit Device Name and Device No.

  • Page 65: Upgrade

    Entrance and Exit Capture Camera User Manual 3. Click Search. The matched log files will be displayed on the log list. 4. Optional: Click Save Log to save the log files to your computer. 9.3 Upgrade Upgrade the system when you need to update the device version. Before You Start Prepare the upgrade file.

  • Page 66: Synchronize Time

    Entrance and Exit Capture Camera User Manual - Click Restore Factory Settings to restore all the parameters to the factory settings. 3. Click OK. 9.6 Synchronize Time Synchronize the device time when it is inconsistent with the actual time. Steps 1.

  • Page 67: Export Parameters

    Entrance and Exit Capture Camera User Manual 3. Set Start Time, End Time, and DST Bias. 4. Click Save. 9.8 Export Parameters You can export the parameters of one device, and import them to another device to set the two devices with the same parameters.

  • Page 68: Export Debug File

    Entrance and Exit Capture Camera User Manual 9.10 Export Debug File The technicians can export the debug file to troubleshoot and maintain the device. Steps 1. Go to Configuration → Device Configuration → System Maintenance → Export Debug File . 2.

  • Page 69: Appendix A. Communication Matrix And Device Command

    Entrance and Exit Capture Camera User Manual Appendix A. Communication Matrix and Device Command Scan the QR code below to get the communication matrix of the device. Figure A-1 Communication Matrix Scan the QR code below to get the device command. Figure A-2 Device Command...
  • Page 70 UD25155B...
