Summary of Contents for Shoprider ROCKY 8
- Page 1 ATTENTION Please read your owner’s manual before driving your scooter. ROCKY 8 Owner’s Manual...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION .....................3 FEATURE GUIDE ....................3 SAFETY ADVICE ....................4 EMI Warning ......................6 ADJUSTMENT ......................8 SCOOTER TILLER CONTROLS ................10 FREE WHEEL OPERATION ...................12 STARTING TO DRIVE YOUR SCOOTER..............13 EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER ......14 BATTERIES AND BATTERY CHARGER ...............15 MAINTENANCE ......................16 TROUBLE SHOOTING GUIDE ................18 WARRANTY TERMS &... -
Page 3: Introduction
Direct drive ® transaxles and electromagnetic brakes give a safe and efficient ride. This Shoprider scooter is designed for persons with limited mobility. Please read this manual carefully and thoroughly before using your scooter and make sure you understand all the instructions. -
Page 4: Safety Advice
SAFETY ADVICE • Do not carry passengers. • This mobility Product is intended to assist you. For your own safety, please read the Owner’s Manual before using the Scooter. If in any doubt, contact your supplier directly for advice. • Do not exceed inclines over 9 degrees (15% grade). •... - Page 5 • Ensure the scooter is serviced every 12 months by an authorised Shoprider service provider to ensure it remains in safe working order. Failure to do so may cause...
-
Page 6: Emi Warning
EMI Warning ® Shoprider scooters may be susceptible to electromagnetic interference (EMI), which is a kind of interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radio, and cellular phones. The interference (from radio wave sources) can cause the scooter to release its brakes, move by itself, or move in unintended directions. - Page 7 EMI. NOTE! There is no easy way to evaluate the overall immunity of the scooter. ® 5. Report all incidents of unintended movement or braking to your Shoprider dealer, and note whether there are sources of EMI nearby.
-
Page 8: Adjustment
ADJUSTMENTS Tiller Angle Adjustment (Fig. 1) The tiller of your scooter is uniquely designed to Tiller Angle allow you to position it to a comfortable driving position. Adjustment Your scooter’s tiller is very versatile, and can be adjusted to different positions. To decide which position best fits your needs, carefully push the black lever that is located on the right side of tiller, and gently lower or USB Port... - Page 9 Seat Slide & Swivel Adjustment (Fig. 4) Pulling up on the seat slide lever allows the seat position to be adjusted forward or backward. Release the lever and the seat will lock in that position. Under the right side of the seat there is a spring loaded red lever.
-
Page 10: Scooter Tiller Controls
SCOOTER TILLER CONTROLS (Fig. 7) Fig. 7 (1) LCD Display Item Description Item Description Odometer Display Temperature Display Speedometer Display Headlight / Taillight Display Battery Gauge Display Right Turn Signal Display “E”: Empty ; “F”: Full High/Low Speed Mode Display E+H Hazard Warning Light Display Left Turn Signal Display... - Page 11 (2 & 3) Speed Controls The speed control allows you to set a speed between 1 (minimum) and 10 (maximum). Turn the dial knob counter-clockwise to “minimum” to decrease speed, and clockwise towards “maximum” to increase your speed. The “High / Low” switch for extra speed. Please use extra caution when using the scooter in “High”...
-
Page 12: Free Wheel Operation
FREE WHEEL OPERATION (Fig. 8) The free wheel release lever (red handle) is located inside the right rear wheel. To disengage the motor, lift up the lever (the scooter can now be pushed). To re-engage the motor push down on the lever. WARNING! Always re-engage the free wheeling device after use. -
Page 13: Starting To Drive Your Scooter
STARTING TO DRIVE YOUR SCOOTER Getting Started • Select a level area with plenty of space. • Mount the scooter, either by lifting the arm and sliding on to the seat or rotate the seat outwards and then rotate the seat back to face the tiller. •... -
Page 14: Extra Guidelines In The Control Of Your Scooter
EXTRA GUIDELINES IN THE CONTROL OF YOUR SCOOTER Ramps The stability of your scooter is governed by several factors such as the seating position, the angle of the slope and your height and weight. When approaching an incline, do so directly and not at an angle and whenever possible avoid making turns. -
Page 15: Batteries And Battery Charger
A/C cord from the wall then unplug the 3-pin lead from the tiller. ® WARNING: Only use the original Shoprider approved charger! This charger is for indoor use only. DO NOT expose it to rain or water spray. -
Page 16: Maintenance
Regular servicing will ensure trouble free operation. Please Note Heavy users of the scooter may require more frequent servicing Consult with your authorised Shoprider dealer to have the servicing requirements completed every year. Lubrication At six-month intervals you should lubricate the following parts with a light oil or similar lubricant: •... - Page 17 Wheels and Tires The wheels of your scooter have split rims. This allows any punctures to be repaired easily. To change the wheels remove the 5 x hex head 6mm and slide the wheel off its axle hub. When changing a tire you must deflate the tire first. Remove the five bolts to split the rim to separate the rim.
-
Page 18: Trouble Shooting Guide
Please consult your dealer if your scooter does not run after checking these points. Please consult your selling Shoprider provider if your scooter does not run after checking these points. -
Page 19: Warranty Terms & Conditions
(18) months from the date of purchase by the original customer. Shoprider Australia will repair or replace, at our option free of charge any part found on examination by Shoprider Australia to be defective in material and or workmanship within the warranty period. - Page 20 NOTE: In the event of a warranty issue, Always contact your selling Shoprider® dealer who will arrange any work and return any faulty parts. Parts will be assessed and replaced within 3-5...
-
Page 21: The Procedure About Front Bumper And Front Light Cover
The procedure about front bumper and front light cover 1. Front bumper bracket face down and push it to bottom. 2. Tighten the bolt and then tighten the nut. 3. Assemble the upper front cover. 4. LED headlight need to put into front light cover. 5. -
Page 22: Technical Specifications
TECHNICAL SPECIFICATIONS Model Name 889AE ROCKY 8 1590(62.5) x 730(29) x Overall Dimensions: L x W x H mm(in) 1285(51) 2 x 13.0 Front Pneumatic Tire Diameter pcs x in 2 x 13.0 Rear Pneumatic Tire Diameter pcs x in... -
Page 23: Disclaimer
This owner's manual is printed based on the latest specifications and product information available at the time of publication. SHOPRIDER® reserves the right to make changes as they become necessary. Any changes to the SHOPRIDER® range may cause slight variations between the illustrations and explanations in this manual and the scooter model that was purchased. -
Page 24: Notes
Notes P/N：300904-162...
