Springfree SF60E Manual page 15

Figure 12-A: The remaining rods attached to the mat
Figure 12-B: The release clip on the mat fitting
Figure 13: The enclosure being slid up the rods and up
onto the mat
Figure 14: The horizontal rods being inserted into
their sleeves in the enclosure
Springfree Trampoline Model SF60E Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
Step 12: Attaching the remaining
rods to the mat
Now, install one more rod to the left of each
group, while circling the trampoline.
Continue to circle around the trampoline
installing one rod per group until all rods are
connected (Figure 12-A).
Tip: If you miscount, and need to release a
connected rod, release the clip before trying to
disconnect the ball from the mat socket. The
Push lever
clip is released by pushing the lever towards
towards mat
centre to
the mat centre. Apply pressure on the rod until
release ball
it is unloaded (Figure 12-B).
Step 13: Sliding the enclosure
net up the rods
Lift the enclosure net from the ground, up on
to the trampoline mat. (It may be a tight fit over
the mat edge.)
Circling the trampoline from right to left,
slide the net bottom strip up the rods to the
top, just under the mat edge. The long zip
will now end along the straight edge of the
trampoline.
Step 14: Inserting the horizontal
net supports
Locate the top edge of the enclosure along the
straight edge of the trampoline.
Slide the horizontal rod into the pocket along
the top enclosure edge and secure with the
Velcro tab (Figure 14).
Repeat on other side of the trampoline.
WARNING: Treat any loaded rod
with caution until you are sure it is
properly installed or uninstalled.
Keep your face well away from any
loaded rod.
15
