Holding the frame section with a pinned end,
insert one end (Figure 1-B) of the pin into the
tab on the outside of the frame.
Rotate the frame downwards so that the
other end of the pin in locked in the inside tab
(Figure 1-C).
Step 2: Assembling the straight
frame sections
Tip: This step is easier Join the two half circles together with the
to perform with two straight frame sections (Figure 2-A). Here's how:
people. Arrange the two half circles so that the
straight frame sections fit between them.
Insert the pins on each end of the straight
section into the outside tabs on the round
sections. When both pins are inserted, twist
the straight section to lock the section in place
(Figure 2-B).
Note: If performing this task by yourself, notice
that the pin on one end of the straight section is
longer: Insert this pin first to assist with aligning
the straight section.
10
Springfree Trampoline Model SF60E Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
Figure 1-B: Pin being inserted into the tab
Figure 1-C: The round frame sections locked together
Figure 2-A: The straight sections attached to the
round sections to make a complete oval shape
Figure 2-B: Twisting the straight section into place
twist and lock
