Model No. PFTL59720-INT.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL
iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Carbon TL PFTL59720-INT.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form Carbon TL PFTL59720-INT.0

Summary of Contents for Pro-Form Carbon TL PFTL59720-INT.0

  • Page 1 Model No. PFTL59720-INT.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 19. When a person is walking on the treadmill, 24. Do not change the incline of the treadmill by the noise level of the treadmill will increase. placing objects under the treadmill. 20. Keep fingers, hair, and clothing away from 25.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new PROFORM reading this manual, please see the front cover of this ® CARBON TL treadmill. The CARBON TL treadmill manual. To help us assist you, note the product model provides an impressive selection of features designed number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (88) to the front of the Base (97). Next, identify the Right Upright (86). Have a second person hold the Right Upright near the Base (97).
  • Page 9 4. Hold the Right Upright (86) against the Base (97). Make sure not to pinch the Upright Wire (88). Insert two 3/8" x 2 3/8" Screws (3) with two 3/8" Star Washers (11) into the top of the bracket on the Right Upright (86).
  • Page 10 6. Identify the Left and Right Handrails (80, 81). Attach the Right Handrail (81) to the Right Upright (86) with two 5/16" x 2 1/4" Screws (7) and two 5/16" Star Washers (12) in the location shown; start both Screws, and then tighten them.
  • Page 11 8. With the help of a second person, hold the con- sole assembly (F) near the Right Upright (86). Next, insert the Upright Wire (88) through the indicated looped tie (G). Connect the Upright Wire (88) to the wire (H) from the console assembly (F).
  • Page 12 10. IMPORTANT: To avoid damaging the Crossbar (87), do not use power tools and do not overtighten the #10 x 3/4" Screws (6). Attach the Crossbar (87) to the Handrails (80, 81) with four #10 x 3/4" Screws (6) and four 1/4"...
  • Page 13 12. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (60) to the upright position. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 14 is completed.
  • Page 14 14. Remove the 5/16" Nut (39) and the 5/16" x 2 1/4" Bolt (117) from the bracket on the Latch Crossbar (48). 39 L Align the upper end of the Storage Latch (84) with the bracket on the Latch Crossbar (48), and insert the 5/16"...

  • Page 15: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord (A) into the tion or break down, earthing provides a path of least socket (B) on the treadmill.
  • Page 16 CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers a selection of features exercise. designed to make your workouts more effective and To turn on the power, see page 17.
  • Page 17 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 18 5. Follow your progress with the displays. To manually advance the scan cycle, press the Scan button repeatedly. The display can show the following workout To turn off the scan mode, press the Display information: button; the scan indicator and the word SCAN will Calories (CALS)—The approximate number of turn off.
  • Page 19 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment ends. The walking belt will then 1. Insert the key into the console. slow to a stop. See HOW TO TURN ON THE POWER on page 17. If the speed or incline setting for the current seg- ment is too high or too low, you can manually over- 2.
  • Page 20 HOW TO CONNECT YOUR TABLET TO THE 5. Disconnect your tablet from the console if CONSOLE desired. The console supports Bluetooth connections to tablets To disconnect your tablet from the console, first via the iFit—Workouts at Home app and to compatible select the disconnect option in the iFit—Workouts heart rate monitors.
  • Page 21 THE SETTINGS MODE Display Test—This screen is intended to be used by service technicians to identify whether the 1. Select the settings mode. display is working correctly. Button Test—This screen is intended to be used To select the settings mode, press the gear button (K).
  • Page 22 Demo Mode—The currently selected demo mode THE OPTIONAL CHEST HEART RATE MONITOR option will appear in the display. The console features a demo mode, designed to be used if the Whether your treadmill is displayed in a store. If the demo mode goal is to is turned on, the console will not turn off and the burn fat or to...

  • Page 23: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 24: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal per- a. Check the power switch (see drawing c above). If formance and to reduce wear. Inspect and properly the switch has tripped, wait for five minutes and tighten all parts each time the treadmill is used.
  • Page 25 SYMPTOM: The displays of the console do not SYMPTOM: The walking belt slows when walked on function properly a. If an extension cord is needed, use only a 3-conduc- a. Remove the key from the console and UNPLUG tor, 14-gauge (2 mm ) cord that is no longer than THE POWER CORD.
  • Page 26 SYMPTOM: The walking belt is not centered SYMPTOM: The walking belt slips when walked on between the foot rails a. First, remove the key and UNPLUG THE POWER IMPORTANT: If the walking belt rubs against CORD. Using the hex key, turn both idler roller the foot rails (D), the walking belt may become screws clockwise, 1/4 of a turn.

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
  • Page 28 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 29 NOTES...

  • Page 30: Part List

    PART LIST Model No. PFTL59720-INT.0 R0820A Key No. Qty. Description Key No. Qty. Description 3/8" x 1 1/4" Screw Rubber Cushion 3/8" x 1 3/4" Screw 3/8" Pin 3/8" x 2 3/8" Screw Drive Roller/Pulley #8 x 3/4" Screw Controller Clamp #8 x 1/2"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Console Frame Clamp Console Ground Wire M4 Nut Console Clamp M4 x 10mm Bolt Key/Clip Filter Console Motor Bushing Console Cable Tie 5/16" x 1 3/4" Bolt Wheel 5/16" x 2 1/4" Bolt 9/32"...

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL59720-INT.0 R0820A...
  • Page 33 EXPLODED DRAWING B Model No. PFTL59720-INT.0 R0820A...
  • Page 34 EXPLODED DRAWING C Model No. PFTL59720-INT.0 R0820A 2 11 11 1...
  • Page 35 EXPLODED DRAWING D Model No. PFTL59720-INT.0 R0820A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
