Toto EGO TX115LEN Manual

SPECIFICATIONS
Lavatory
Ø60
H C
G1¼
G½
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
Don't use abrasive cleaning material such as; detergents
1.
containing hydrochloric acids, thinner, polishing powder,
and nylon brush.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S06157R
INSTALLATION
1.
Faucet
Packing
Ø35 Hole
To Hot
119
Water Supply
TOTO
Ø42
2.
max. 230
3.
"EGO" SINGLE LEVER LAVATORY FAUCET
Lift rod
Setting Bolt
Washer
Setting Nut
To Cold Water Supply
C
Plug
Siphon
Packing
Triangle
Packing
Nut
Washer
Pivot Rod
Kick Box
Packing
Bottom
Position
OPEN
Position
Bolt
Pop-Up Clip
Bolt
W/ 1¼" POP-UP WASTE
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Flow rate unsatisfactory
Water leaks around the handle
Handle is loose
Plug cannot open and close
Body swinging
2. CONNECTING NUT
3. BOLT
1. AERATOR
H
MAINTENANCE
Always wipe plated area with dry soft cloth, and sometimes
wipe it with cloth soaked in mild soap.
TX115LEN
SOLUTION
1
Remove and clean
2 Tighten
3 Tighten
4 Tighten
5 Tighten
5. SETING NUT
4. BOLT
C
R6
