Toto ALISEI TX115LX Installation

SPECIFICATIONS
48
Ø62
Ø31.75
max. 300
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
1.
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and are
not recommended for cleaning
2. Release the pop-up waste plug for cleaning the pop-up waste
from dirt.
S060316R
INSTALLATION
1.
128
45
Hot Water Supply
2.
G½
3.
"ALISEI" SINGLE LEVER LAVATORY FAUCET
W/ 1" ONE PUSH POP-UP WASTE
Faucet
Packing
Ø35 Hole
Setting Bolt
Washer
Slip Washer
Setting Nut
Cold Water Supply
C
Plug
Siphon
Use seal tape
on the Thread
Packing
( Not Include)
Triangle
Packing
Nut
Nut
Pipe
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Water leaks around the handle
Handle is loose
Body swinging
2. B OLT
1. CONNECTING NUT
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
TX115LX
SOLUTION
1 Tighten
2 Tighten
Tighten
3
Use Hex. Socket Key
(Not include)
3. S ETTING NUT
R4
