Toto MONO TX119LMBR Quick Start Manual

SPECIFICATIONS
100 100
Ø42
48
Ø62
G½
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.)
MAINTENANCE
1. All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
2. Release the pop-up waste plug for cleaning the pop-up waste
from dirt.
S06889BR
INSTALLATION
1.
3 X Ø35
128
3.
Ø31.75
Ø35 Hole
max. 300
5.
Siphon
Packing
Triangle
Packing
Nut
Nut
Pipe
"MONO" 8" LAVATORY FAUCET
w/ 1" ONE PUSH POP-UP WASTE
2.
Handle Set*
Hex. Key
Bolt
Lock Nut
Ø35 Ceramic
Hole Head Work
Packing
Lock Nut
Body
* The red handle for left position and
the blue handle for right position.
4.
Spout
Packing
Setting
Hot
Bolt
Water
Supply
Washer
Slip
Washer
Cold
Water
Setting
Supply
Nut
Flexible Hose
6.
Plug
Use seal tape
on the Thread
( Not Include)
TX119LMBR
TROUBLESHOOTING
CHECK
PROBLEM
POINT
1
Water leaks around the handle
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
installation principles are the same.
SOLUTION
Tighten
1. CERAMIC
HEAD
WORK
R3
