Toto EGO II TX119LECBR Quick Start Manual

SPECIFICATIONS
100 100
Ø54
Ø54
G½
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S06483BR
INSTALLATION
1.
163
105
3.
Ø60
Ø35 Hole
G1¼
max.230
5.
Plug
Siphon
Packing
Kick Box
"EGO II" 8" CROSS HANDLE LAVATORY FAUCET
2.
Handle Set *
3 X Ø35
Handle Base **
Lock Nut
Ceramic
Ø35
Head Work
Hole
Packing
Lock Nut
Body
* Red handle for lef t side and
blue handle for right side.
**Tighten the handle base by hand
4.
Spout
Packing
Setting Bolt
Hot
Water
Washer
Supply
Flexible
Hose
Setting Nut
Flexible
Lift rod
Hose
6.
Bottom
Washer
ON
Nut
Pivot
Rod
Packing
Bolt
Pop-Up Clip
W/ 1¼" POP-UP WASTE
TROUBLESHOOTING
PROBLEM
Flow rate unsatisfactory
Water leaks around the handle
Plug cannot open and close
Body swinging
1. AERATOR
Cold
Water
Supply
MAINTENANCE
Bolt
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
TX119LECBR
CHECK
SOLUTION
POINT
1 Remove and clean
2 Tighten
3 Tighten
4 Tighten
2. CERAMIC
HEAD WORK
4. SETTING NUT
3. BOLT
R3
