- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ™ Installation Instructions for Ice Storage Bins HCD/HMD/HCF/HMF1810RBS, HCD/HMD/HCF/HMF2110RBS HCD/HMD1810NBS, HCD/HMD2110NBS (See model number configurator on page 2 for details.) Order parts online www.follettice.com remote condensing 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Docking assembly Ice transport tube External connection Internal connection Front cover BIN • RIDE Technology self-contained...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ BIN • RIDE Technology...
-
Page 5: Site Preparation
• 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable federal, state, and local codes Drains: ➌... -
Page 6: Before Proceeding
Bin preparation Prepare the bin. Bin top preparation Bin top preparation 3" ∅ (76,2mm) • Remove protective tape from • Locate center of bin top gaskets • Cut 3" (77,2mm) diameter hole in bin top BEFORE PROCEEDING Bin top preparation —... - Page 7 Docking assembly Install the docking assembly. Wall bracket accessory Machine stand accessory • Mount docking assembly to wall bracket • Mount docking assembly to machine accessory stand accessory Docking assembly 2" (50,8 mm) 1.81" (46 mm) ➋ ➊ 3/8˝ ∅ 2"...
- Page 8 Transport tube Install the ice transport tube. Ice transport tube installation ➍ ➏ ➐ ➋ Hot Water 160 F (71 C) ➑ ➎ ➒ ➊ ➓ 1/4" ➌ Ice transport tube tips • Insulate entire length of ice transport tube ➊...
-
Page 9: External Connections
External connections Connect utilities to docking assembly. Chassis drain plumbing - required Water and drain ➊ ➋ ➌ Minimum 8" ➏ radius • Plug must be removed from John Guest 2 ft. x 1" OD fitting. silicone tubing • Route 3/8" drain tubing through knockout in back of docking station and insert fully into John Guest fitting connection at the 3/4"... -
Page 10: Internal Connections
Internal connections Connect docking assembly to ice machine. Ice transport tube installation Water line ➋ ➊ ➌ Mount water ➋ solenoid ➊ • Slide ice machine into docking assembly • Mount water solenoid to inside rear of ensuring that drain tube is fully seated on docking assembly using one screw ➊... - Page 11 Power cord TDS switch HIGH CLEAN • Position plate into opening and secure • Set the TDS switch on the electrical box: with supplied screw HIGH: for extended service life LOW: for low-scale water BIN • RIDE Technology self-contained...
-
Page 12: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover • Complete installation of condensing unit slip under louvers on back of docking or connection to rack system. - Page 13 Long tube run recommendations max. 2 ft (.6m) ➊ ➋ 1/4" • Pitch ice transport tube to allow melt water to drain towards ice machine ➊ • Secure insulated ice transport tube at least every 2 ft (.6m) to prevent dips or traps ➋...
- Page 14 BIN • RIDE Technology self-contained...
- Page 15 BIN • RIDE Technology self-contained...
- Page 16 Horizon, Horizon Elite, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge, RIDE and Vision are trademarks of Follett Products LLC. Chewblet is a registered trademark of Follett Products LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 01157874R02 www.follettice.com...
