HCD/HMD/HCF/HMF1810RVS, HCD/HMD/HCF/HMF2110RVS
HCD/HMD1810NVS, HCD/HMD2110NVS
(See model number configurator on page 2 for details.)
Order parts online
www.follettice.com
Horizon Elite
Ice Machine Models with RIDE
™
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Installation Instructions for Vision
Technology
®
™
remote condensing
01157858R01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Horizon Elite HCD1810RVS
Summary of Contents for Follett Horizon Elite HCD1810RVS
- Page 1 Horizon Elite Ice Machine Models with RIDE Technology ™ ® Installation Instructions for Vision ™ HCD/HMD/HCF/HMF1810RVS, HCD/HMD/HCF/HMF2110RVS HCD/HMD1810NVS, HCD/HMD2110NVS (See model number configurator on page 2 for details.) Order parts online www.follettice.com remote condensing 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
- Page 2 Chewblet Ice Machine Model Number Configurations ® 1810 Application Configuration Icemaker Voltage Series Condenser MC Maestro™ C 208-230/60/1 (icemaking head) 425 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 425 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (193 kg)
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover VISION • RIDE Technology remote condensing...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➋ ➌ ➊ ➎ ➍ 7/16" DO NOT TILT ICE MACHINE TO ACCESS BOLTS! COMPRESSOR DAMAGE 7/16" WILL RESULT ➐ ➏ VISION • RIDE Technology...
-
Page 5: Site Preparation
• 10-70 psi (69-483kpa) • 45-90 F (7-32 C) • Follett recommends the use of an in-line water filtration system (item# 00130286) • This equipment is to be installed with adequate backflow protection to comply with applicable federal, state, and local codes Drain ➌... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Bin Signal Installation ➏ ➎ ➐ ➌ 24" (610 mm) ➋ Ground ➊ ➌ • Mount the electrical box to the side of the Vision dispenser ➊ to establish a ground connection. Note: If a 4 x 4 box is mounted to a non-grounded surface, connect ground wire at an appropriate ground. -
Page 7: Before Proceeding
Louvered docking assembly Install the louvered docking assembly. BEFORE PROCEEDING Prior to installing the louvered docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. An optional straight drain fitting is also supplied. You may need to remove the back panel of the docking assembly in order to re-orient or change the drain fitting. -
Page 8: Docking Station
Undercounter installation requirements Top View ➌ ➊ 3.25" (83 mm) min. Access panel/ door on counter 23.5" min. (59.7 mm) 24" min. (61 mm No Lip ➋ DOCKING STATION • Prior to installing the louvered docking assembly, ensure that the drain fitting is oriented (right or left) correctly for your installation. - Page 9 Transport tube Install the ice transport tube. Dispenser ice transport tube installation Ice tube retainer bracket 1" (25mm) ice tube retaining bracket ice tube ice tube Front View Front View VU155 VU300 ice tube retaining bracket thermostat thermostat ice tube retaining bracket tabs in ice tube...
- Page 10 Ice transport tube installation. Hot Water 160 F (71 C) 1/4" Ice transport tube tips ➊ • Insulate entire length of ice transport tube ➋ • Secure ice transport tube as needed to prevent dips and traps from forming. For long tube runs see guide on page 15. •...
-
Page 11: External Connections
External connections Connect utilities to louvered docking assembly. Water and drain Refrigerant ➊ ➋ ➊ ➌ Minimum 8" ➏ radius 2 ft. x 1" OD silicone tubing • Braze supplied quick-connect lines onto ➊ stub-ins 3/4" barb x 3/4" FPT ➍... -
Page 12: Internal Connections
Internal connections Connect louvered docking assembly to ice machine. Ice transport tube installation Water line ➋ ➊ ➊ • Slide ice machine into louvered docking ➊ • Insert potable water line into valve assembly ensuring that drain tube is fully ➊... - Page 13 Power cord TDS switch HIGH CLEAN • Position plate into opening and secure • Set the TDS switch on the electrical box: with supplied screw HIGH: for extended service life LOW: for low-scale water VISION • RIDE Technology remote condensing...
-
Page 14: Front Cover
Front cover Install front cover to ice machine. Install condensing unit Install ice machine front cover ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of louvered • Complete installation of condensing unit docking assembly ➊... - Page 15 Long tube run recommendations max. 2 ft (.6m) 1/4" • Pitch ice transport tube to allow melt water to drain towards ice machine ➊ • Secure insulated ice transport tube at least every 2 ft (.6m) to prevent dips or traps ➋...
- Page 16 Horizon, Horizon Elite, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge and Vision are trademarks of Follett LLC. Chewblet, RIDE and Follett are registered trademarks of Follett LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA 01157858R01 Toll free (877) 612-5086 • +1 (610) 252-7301 ©...
